ASUS MB TUF GAMING -PLUS Intel,1200,DDR4,mATX

LGA 1200, Intel B560, mATX
6Ratings
BrandMore from ASUS
Currently out of stock

Product details

The ASUS TUF Gaming B560M-Plus utilizes all the essential elements of Intel processors and combines them with gaming-ready features and proven durability. This motherboard is equipped with military-grade components, an enhanced power solution, and a comprehensive cooling system, providing solid, stable performance for marathon gaming sessions. Aesthetically, the TUF Gaming B560M-Plus showcases the TUF Gaming logo and incorporates simple geometric design elements to reflect the reliability and stability that define the TUF Gaming series.

Key specifications

Processor family
Core i3 10th Gen, Core i3 11th Gen, Core i5 10th Gen, Core i5 11th Gen, Core i7 10th Gen, Core i7 11th Gen, Core i9 10th Gen, Core i9 11th Gen
Memory type
DDR4-RAM
Number of memory modules (RAM)
4 x
Internal connection options
24-pin ATX power connector (1x), 8-pin ATX 12V (1x), M.2 (2x), S-ATA III (6x)
Mainboard features
Front panel audio connector
Item number
14985745

General information

Manufacturer
ASUS
Category
Motherboards
Manufacturer no.
90MB1780-M0EAY0
Release date
9.3.2021

Motherboard properties

Form factor
Micro ATX (mATX)
Socket
LGA 1200
Chipset
Intel B560
Mainboard features
Front panel audio connector
Operating system compatibility
Windows 10
BIOS type
UEFI AMI

Processor

Processor family
Core i3 10th Gen, Core i3 11th Gen, Core i5 10th Gen, Core i5 11th Gen, Core i7 10th Gen, Core i7 11th Gen, Core i9 10th Gen, Core i9 11th Gen

Memory

Memory form factor
DIMM
Number of pins
184 x
Number of memory modules (RAM)
4 x
Max. memory (RAM)
128 GB
Supported memory speed
2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3200 MHz, 4000 MHz, 4400 MHz, 4800 MHz
Memory type
DDR4-RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
DisplayPort (1x), HDMI (2x)
Video connection version
HDMI 2.0

Network

Network connections
RJ45 (1x)
Ethernet controller brand
Intel
Max. port speed
2.50 Gbit/s

Audio

Chip
Realtek ALC887
Audio Connections
Audio In

Internal interfaces

Internal connection options
24-pin ATX power connector (1x), 8-pin ATX 12V (1x), M.2 (2x), S-ATA III (6x)
Expansion slot
PCI Express x1 (Gen 3) (1x), PCI Express x16 (Gen 4) (1x)
Number of fan connector
2

Further connections

USB ports
USB-C
Exact USB ports
USB-A 2.0 (2x), USB-A 3.2 Gen 1 (1x), USB-A 3.2 Gen 1 (3x), USB-A 3.2 Gen 2 (1x)

Power supply

Power connectors
24-pin ATX, 8-pin ATX 12V

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Sata Cables

Product dimensions

Length
244 mm
Width
244 mm
Height
68 mm
Weight
1350 g

Package dimensions

Length
28 cm
Width
28 cm
Height
7 cm
Weight
1.37 kg
