AsRock H510M-H2/M.2 SE

LGA 1200, Intel H470, mATX
Ratings
BrandMore from AsRock
Delivered between Fri, 16.5. and Thu, 22.5.
More than 10 items in stock at supplier

Product details

The PCIe Gen3 x4 Ultra M.2 interface enables data transfer speeds of up to 32 Gb/s. Additionally, it also supports SATA3 6 Gb/s M.2 modules.

Key specifications

Processor family
Core i3, Core i5, Core i7, Core i9
Memory type
DDR4-RAM
Number of memory modules (RAM)
2 x
Internal connection options
M.2 (1x), S-ATA III (4x)
Mainboard features
Front panel audio connector, Trusted Platform Module
Item number
40244966

General information

Manufacturer
AsRock
Category
Motherboards
Manufacturer no.
90-MXBMQ0-A0UAYZ
Release date
27.11.2023

Motherboard properties

Form factor
Micro ATX (mATX)
Socket
LGA 1200
Chipset
Intel H470
Mainboard features
Front panel audio connector, Trusted Platform Module
Operating system compatibility
Windows, Windows 10
BIOS type
UEFI AMI

Processor

Processor family
Core i3, Core i5, Core i7, Core i9

Memory

Memory form factor
DIMM
Number of memory modules (RAM)
2 x
Max. memory (RAM)
64 GB
Memory chip
DDR4 RAM
Supported memory speed
2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3200 MHz
Transfer rate
3.20 MT/s
Memory type
DDR4-RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
HDMI (1x), HDMI (2x)

Network

Network connections
RJ45 (1x)
Ethernet controller brand
Realtek
Ethernet controller
Realtek RTL8111H
Max. port speed
1 Gbit/s

Audio

Chip
Realtek ALC897
Audio channel
7.1 Channel
Audio Connections
HDMI (2x), Jack 3.5mm Line Out (1x)

Data storage

RAID configuration
0, 1, 10, 5

Internal interfaces

Internal connection options
M.2 (1x), S-ATA III (4x)
Expansion slot
PCI Express x1 (1x), PCI Express x16 (1x)
PCI express version (max.)
4

Further connections

USB ports
USB-A
Exact USB ports
USB-A 2.0 (2x), USB-A 3.2 Gen 1 (4x)

Power supply

Power connectors
24-pin ATX, 8-pin ATX 12V

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Sata Cables

Product dimensions

Length
231 mm
Width
187 mm
Weight
620 g

Package dimensions

Length
28 cm
Width
22 cm
Height
6 cm
Weight
670 g
