AsRock B760M Steel Legend

LGA 1700, Intel B760, mATX
2Ratings
BrandMore from AsRock
Delivered between Tue, 7.4. and Wed, 8.4.
10 pieces in stock at supplier
free shipping

Product details

Steel Legend represents the philosophical state of absolute durability and irresistible aesthetics. The Steel Legend series is based on the most demanding specifications and features, targeting everyday users and mainstream enthusiasts. It offers a strong selection of materials and components to ensure stable and reliable performance. Dr. MOS is the integrated power stage solution optimized for synchronous buck voltage applications. Compared to conventional discrete MOSFETs, it intelligently delivers higher current for each phase, resulting in improved thermal performance and superior efficiency.

Key specifications

Mainboard features
Front panel audio connector, RGB header
Wireless transmission
Bluetooth
Processor family
Core i3 12th Gen, Core i3 13th Gen, Core i5 12th Gen, Core i5 13th Gen, Core i7 12th Gen, Core i7 13th Gen, Core i9 12th Gen, Core i9 13th Gen
Number of memory modules (RAM)
4x
Internal connection options
M.2 (1x), M.2 PCIe (1x), S-ATA III (4x)

General information

Item number
23852986
Manufacturer
AsRock
Category
Motherboards
Manufacturer no.
90-MXBL70-A0UAYZ
Release date
3.1.2023

Motherboard properties

Form factor
Micro ATX (mATX)
Socket
LGA 1700
Chipset
Intel B760
Mainboard features
Front panel audio connector, RGB header
Operating system compatibility
Windows, Windows 10
BIOS type
UEFI AMI
Wireless transmission
Bluetooth
Wi-Fi standard
Wi-Fi 6 / 802.11ax

Processor

Processor family
Core i3 12th Gen, Core i3 13th Gen, Core i5 12th Gen, Core i5 13th Gen, Core i7 12th Gen, Core i7 13th Gen, Core i9 12th Gen, Core i9 13th Gen

Memory

Memory form factor
DIMM
Number of memory modules (RAM)
4x
Max. memory (RAM)
128 GB
Memory chip
DDR5 SDRAM
Max. RAM OC
7200 MHz
Transfer rate
7200 MT/s
RAM buffer
Unbuffered

Graphics properties

Video connections
DisplayPort, HDMI Type A
Video connection version
Display port 1.4, HDMI 2.1

Network

Ethernet controller brand
Realtek
Ethernet controller
Dragon RTL8125BG
Max. port speed
2.50 Gbit/s

Audio

Chip
Realtek ALC897
Audio channel
7.1 Channel

Internal interfaces

Internal connection options
M.2 (1x), M.2 PCIe (1x), S-ATA III (4x)
Expansion slot
PCI Express x16 (Gen 5) (1x)
Number of fan connector
5

Further connections

USB ports
USB-A
Exact USB ports
USB-A 2.0 (2x), USB-A 3.2 Gen 1 (4x)

Power supply

Power connectors
24-pin ATX, 8-pin PCI-E

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
1579.07 kg
Climate contribution
CHF 6.25

Scope of delivery

Scope of delivery
SATA cable

Product dimensions

Length
244 mm
Width
244 mm
Height
260 mm
Weight
400 g

Package dimensions

Length
28.70 cm
Width
26.90 cm
Height
6.70 cm
Weight
1.37 kg
