Product details
Beneath its unrelenting appearance lies a wealth of game-oriented features and excellent gameplay options. Everything revolves around providing players with a modern gaming experience.
Processor family | Ryzen 3rd generation |
Memory type | DDR4-RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | M.2 PCI/SATA Combo (1x), M.2 PCIe (1x), S-ATA III (4x) |
Wireless transmission | Bluetooth, Wi-Fi |
Mainboard features | Clear CMOS Button |
Item number | 13348335 |
Manufacturer | AsRock |
Category | Motherboards |
Manufacturer no. | 90-MXBD00-A0UAYZ |
Release date | 17.6.2020 |
External links |
Form factor | ATX |
Socket | AM4 |
Chipset | AMD B550 |
Mainboard features | Clear CMOS Button |
Operating system compatibility | Windows, Windows 10 |
BIOS type | UEFI AMI |
Wireless transmission | Bluetooth, Wi-Fi |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Processor family | Ryzen 3rd generation |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 128 GB |
Memory chip | DDR4-3000, DDR4-3200, DDR4-3600 |
Max. RAM OC | 4733 MHz |
Supported memory speed | 2133 MHz, 2400 MHz, 2933 MHz, 3200 MHz, 4000 MHz, 4400 MHz |
Memory type | DDR4-RAM |
RAM buffer | Unbuffered |
Video connections | HDMI (1x) |
Video connection version | Display port 1.4, HDMI 2.1 |
Multi-GPU technology | AMD 3-Way CrossFireX, AMD CrossfireX, AMD Quad-GPU CrossFireX |
Network connections | RJ45 (1x) |
Ethernet controller brand | Intel |
Ethernet controller | Intel WGI225V |
Max. port speed | 2.50 Gbit/s |
Chip | Realtek ALC1220 |
Audio channel | 7.1 Channel |
Audio Connections | Coaxial S/PDIF (1x) |
RAID configuration | 0, 1, 10 |
Internal connection options | M.2 PCI/SATA Combo (1x), M.2 PCIe (1x), S-ATA III (4x) |
Expansion slot | PCI Express x16 (3x) |
PCI express version (max.) | 4 |
Number of fan connector | 5 |
USB ports | USB-A |
Power connectors | 8-pin PCI-E |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Sata Cables |
Length | 244 mm |
Width | 305 mm |
Height | 125 mm |
Weight | 465 g |
Length | 31 cm |
Width | 12.50 cm |
Height | 38 cm |
Weight | 3 kg |
Specifications may include unverified machine translations.
