Absima Servo HV Digital Alu ST18DBF 18KG Race-Spec.

Ratings
Delivered Wed, 9.7.
Only 2 pieces in stock at third-party supplier
Supplied by
Conrad CH
free shipping

Product details

Servos are part of the RC system and thus the foundation of a remote-controlled model. They are connected to the steering linkage and translate stick or rotary movements on the transmitter into steering movements on the vehicle. In combustion engine vehicles, they also function as throttle servos, operating both the throttle of the carburetor and the brake. An undersized servo has a longer response time and a shorter lifespan under load. Therefore, never skimp on the servo! A good servo doesn't have to be expensive, but it makes the model more reliable and lasts for years. For 1/8 and 1/10 scale RC cars, only standard size or low-profile servos are used. Our Race Spec servos are designed for competition, but they are also fantastic for ambitious club racers and hobbyists!

Technical Data Highlights:
Servo Category: High-Speed Servos
Operating Voltage: 4.8 - 8.4V HV
Torque / Speed @ 4.8V: 14.0kg / 0.080sec/60°
Torque / Speed @ 6.0V: 15.0kg / 0.072sec/60°
Torque / Speed @ 7.4V: 16.5kg / 0.065sec/60°
Torque / Speed @ 8.4V: 17.5kg / 0.058sec/60°
Technology: Digital
Motor Type: Brushless
Gear Material: Reinforced Steel
Housing Material: AL6061 T6 - CNC machined with plastic insert
Waterproof Rating: IP65 waterproof
Bearings: Metal ball bearings (2)
Size: 40*20*37.5 mm
Weight: 73.0 g
Programmable: Yes, with USB interface adapter # 2030110 (sold separately).

Key specifications

Servo Technology
Digital
moment of force
15 kg/cm
Item number
37382114

General information

Manufacturer
Absima
Category
RC servos
Manufacturer no.
AB2030104
Release date
5.8.2023

Material

Material group
Metal
Material
AL6061 T6 housing with plastic inlay, High-strength steel

RC servo properties

Servo Technology
Digital
moment of force
15 kg/cm
Bearing type
Ball bearing

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
USB interface adapter # 2030110 (sold separately), Waterproof

Product dimensions

Length
4.08 cm
Width
2.02 cm
Height
2.72 cm
Weight
54.20 g

Package dimensions

Length
10.10 cm
Width
8.90 cm
Height
4.20 cm
Weight
104 g

30-day right of return
24 Months Warranty (Bring-in)
