Best Siemens products in the Residual-current device category
On this page you'll find a ranking of the best Siemens products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Siemens 5SV13166KK13
FI/LS compact 1P+N 6kA type A 30mA B13 The RCD is the residual current device for touch protection The patented residual current devices from Siemens are an important part of the SENTRON protection components for electrical installations, because they prevent life-threatening electrical accidents by safely switching off dangerous residual currents to earth. Electrically ignited fires can be prevented while they are still developing. Whether by direct contact with operationally live parts or by indirect contact with equipment - protection is achieved primarily by rapid disconnection. The Siemens 5SV residual current circuit-breakers are characterised above all by: 1. comprehensive protection for persons and property against electric shock. 2. sinusoidal AC residual currents or smooth DC residual currents - Siemens offers the right type and special versions for all requirements. 3. reliable safety during installation thanks to st.
2. Siemens RCBO type A 30mA, 10kA, 1+N-pole B 13A
Range = Sentron
Series = 5SU1
Rated current = 13 A
Trigger sensitivity = 30
Number of poles = 2
Mounting type = DIN rail mounting
Total width = 90mm.
3. Siemens Ground fault circuit interrupter 1 pole 16 A
Tripping fault current 30 mA.
4. Siemens Automatic circuit breaker 1-pole 10A type C
Range = Sentron
Series = 5SY4
Number of poles = 1
Rated current = 10 A
Tripping characteristic = Type C
AC rated voltage = 400 V
Breaking capacity = 10 kA
Length = 89.8mm
width = 17.6mm
Depth = 76.4mm
Automatic cut-off, 5SY4 series, 10 kA, B, C and D. Miniature overload switches from Siemens offer the highest quality and reliability. With the excellent technical features of the devices, you are always on the safe side. In addition, you benefit from the innovative mounting options that enable quick and easy installation. Siemens miniature overload switches can be combined with a wide range of additional components as required, e.g. control current switches, fault signal contacts, shunt releases, undervoltage releases, remote control mechanisms or with RCD units for the protection of persons and against fire. Features and Benefits. Automatic breakout, 1-, 2-, 3- and 4-pole DIN rail mounting For use in industrial and functional and residential construction sectors Supports quick and convenient removal from the assembly. Standards. IEC 60898 - Refers to low voltage circuit breakers for use in domestic and similar installations. Traditionally known in the UK as circuit breakers (miniature circuit breakers,). Q: What are the differences in tripping characteristics B, C and D?.. A: Characteristic, B: Tripping: 3 to 5 times rated current. Applications: Protection of generators, people, very long cables Characteristic, C: Tripping: 5 to 10 times rated current Applications: Protection of circuits and general applications Characteristic D: Tripping: 10 to 14 times rated current Applications: Protection of high voltage circuits, welders, transformers and motors.
5. Siemens Circuit breaker 5SL6516 6 B16A 1+Npole 6kA
Circuit breaker 5SL6516-6 B16A 1+Npole 6kA.
Residual-current device
Quantity discount
CHF13.10 per piece for 2 units
Siemens Circuit breaker 5SL6516 6 B16A 1+Npole 6kA
6. Siemens Circuit breaker 3VA1 ICU=36kA 3pole
Range = Sentron
Series = 3VA
Number of poles = 3
Rated current = 125 A
breaking capacity = 36 kA
AC nominal voltage = 690 V
DC nominal voltage = 500V
Mounting type = Fixed
Length = 76.2mm
width = 130mm
depth = 88mm
diameter of mounting hole = 4.2mm
Siemens circuit-breaker 3VA1. The new 3VA1 encapsulated circuit breakers reliably perform all tasks associated with line protection. The devices of the 3VA1 series meet all standard requirements for line protection. Thanks to their particularly compact design, the 3VA1 series circuit-breakers are the perfect choice for applications in distribution boxes and mechanical engineering. They are easy to install as fixed or plug-in versions. The basic trip for overload or short circuit protection is a thermal-magnetic electronic trip unit (TMTU), and it is suitable for use in three-phase AC and DC networks. Compact design Thermal-magnetic trip units AC/DC applications Without power reduction up to +50 °C.
7. Siemens RCD short time delayed 63A 3ma
Residual current circuit breaker 4 pole.
8. Siemens SIEM circuit breaker
9. Siemens SIEM 5SJ4316-7HG41 Miniature circuit breaker 240V 14kA 3-pole C, 16A, T=70mm according to UL
Siemens 5SJ43167HG41 Power protection.
Residual-current device
CHF189.–
Siemens SIEM 5SJ4316-7HG41 Miniature circuit breaker 240V 14kA 3-pole C, 16A, T=70mm according to UL
10. Siemens Circuit breaker UC B 25A 1+N 400V 5SY7525-6
Siemens Dig.Industr. miniature circuit breaker 5SY7525-6 Manufacturer :Siemens Dig.Industr. Designation :Miniature circuit breaker 230V 15kA 1+N B 25A Type :5SY7525-6 Mounting depth :70 mm Tripping characteristic :B Number of poles (total) :2 Number of fused poles :1 Rated current :25 A Rated voltage :230 V Rated insulation voltage Ui :250 V Rated impulse withstand voltage Uimp :4 kV Rated breaking capacity Icn to EN 60898 at 230 V :15 kA Voltage type :AC Rated breaking capacity Icn to EN 60898 at 400 V :15 kA Rated breaking capacity Icu to IEC 60947-2 at 230 V :25 kA Rated breaking capacity Icu to IEC 60947-2 at 400 V :25 kA Frequency :50 Hz Energy limitation class :3 Flush mounting :no Neutral conductor to be connected :yes Overvoltage category :3 Degree of pollution :3 Additional devices possible :yes Width in pitch units :2 Protection class (IP) :IP20 Ambient temperature during operation :-40..70 °C Connectable conductor cross-section stranded :0.75..35 mm² Connectable conductor cross-section solid :0.75..35 mm² Explosion-proof :no Siemens Dig.Industr. Miniature circuit-breaker 5SY7525-6: further details Miniature circuit-breaker 230V 15kA, 1+N-pole, B, 25A, T=70mm Miniature circuit-breaker SENTRON 5SY for safe short-circuit and overload protection for residential buildings, functional buildings and special industrial applications.Tool-free mounting and dismounting of the device with the aid of a double slide. Any combination of conductors and busbar by means of double-chamber terminal. Simple wiring of the feeder due to the busbar located at the rear.5SY miniature circuit breakers are available in 1-, 2-, 3-, 4- as well as 1+N- and 3+N-pole versions.All accessories can be used uniformly for all 5SY miniature circuit breakers.Simply safe with SENTRON's protective devices. , EAN: 4001869191614.
