Best selling Network cables from Lightwin
On this page you’ll find a ranking of the best Network cables from Lightwin. To give you a quick overview, we’ve added the most important product details. This page always stays fresh and updates automatically.
1. Lightwin Network cable
The new KAT6A LIGHT patch cables from the SLIM brand set new standards in network technology. These thin cables facilitate patching for 10 Gigabit applications thanks to their extremely flexible and slim design.
The LIGHT patch cables are round, twisted pair, shielded, and meet the requirements for transmitting 10, 100, 1000 MBit, and now even 10 Gigabit.
Another significant advantage of the LIGHT patch cables is the flame-retardant outer jacket material and a special RJ45 connector, which features a unique material that prevents the latch from breaking. The latch can be bent back and forth hundreds of times without breaking.
Power over Ethernet transmission according to IEEE802.3af and IEEE802.3at is also possible. Additionally, this cable features our specially developed end design, characterized by easy pressing of the latch and a narrow, short form factor.
Typical application areas for the LIGHT patch cables include:
- Overcrowded server or network cabinets or cable ducts
- Switches with high port densities: With very short cables, you can easily patch from switch to switch or switch to panel without a cable management panel
- Connecting end devices at the desk (VoIP phones, printers, PCs, laptops), as the cables are extremely flexible and easy to lay on a desk
- Applications in industry or manufacturing where Ethernet connections are needed but space is limited
- As a patch cable in the technician's or field worker's laptop bag
- In private settings, to run a patch cable under the carpet, along the chair rail, or even through a window seal.
2. Lightwin Fiber optic cable
A conventional electrical signal in a copper cable is disrupted by electromagnetic interference. In contrast, optical fiber cables provide better protection against disturbances and are also more secure against eavesdropping. Additionally, the low attenuation of optical cables allows for long-distance transmission. The LC connector is a high-performance fiber optic connector for singlemode and multimode applications, featuring an insertion loss of only 0.1 dB and a return loss of 55 dB. The design of the LC connector is based on a single-fiber ceramic ferrule with a diameter of 1.25 millimeters for a fiber optic cable. The OS designation for a fiber optic cable defines the quality class of a singlemode fiber optic cable. The classification distinguishes between two classes (OS1 and OS2), based on the level of optical attenuation and the possible transmission rate and distance.
3. Lightwin LWL Simplex
A conventional electrical signal in a copper cable is disrupted by electromagnetic oscillations. In contrast, optical fiber cables provide better protection against interference and are also more secure against eavesdropping. Additionally, the low attenuation of optical cables allows for long distances to be covered.
4. Lightwin LWL Duplex Patch Cable
The fiber optic cable consists of three layers. The core of the optical medium has a diameter of 50 µm and is made of glass. This core transmits the information. It is surrounded by a cladding with a diameter of 125 µm, which reflects stray light. The outer coating serves to protect against mechanical damage and is made of plastic.
5. Lightwin FO splice box, 12 fibers, 6x DLC multimode, 50/125µm OM4 pigtail splice boxes
LWL splice box, 12 fibers, 6x DLC multimode, 50/125µm OM4 pigtail. Fully equipped and splice-ready splice box. Includes couplings and pigtails. 19' rack mount with 1U. Pigtails are already pre-installed for splicing. Integrated fiber management within the splice box. Material: Metal housing made of powder-coated steel, RAL 7035, splice cassettes made of plastic.
Application: The splice box serves as a handover point between the fiber optic installation cable and the internal network cabling of the building. The fiber optic cable is spliced in the splice cassette and divided into pigtails. All common connector types are possible, e.g., LC, SC, or ST. The installation of the splice boxes usually takes place in 19' network or server racks. To save valuable time during installation, we offer the splice boxes fully equipped and splice-ready. The box is available in gray (RAL 7035). The equipment options are very comprehensive.
Network cables
CHF151.– CHF100.67/1m
Lightwin FO splice box, 12 fibers, 6x DLC multimode, 50/125µm OM4 pigtail splice boxes
1.50 m
6. Lightwin FO patch cable LC/APC-LC/APC, singlemode, simplex, 2m
High-quality Simplex fiber optic patch cable, 2 m, SM, LC/APC - LC/APC. Cable length: 2 m. Fiber quality: Singlemode (9/125 µm). Simplex. Connectors: LC/APC - LC/APC. Serial number on each cable.
General information about fiber optic cables: Equivalent terms for fiber optic patch cables can include patch cords, adapter cables, connection cables, or jumpers. While a conventional signal in a copper cable can be subject to electrical interference, fiber optic cables operate using light. Therefore, they cannot be influenced by external electromagnetic interference, nor do they affect other lines or signals, as they emit no radiation. Additionally, due to the low attenuation of optical cables, distances of well over 100 km can be covered without optical amplification.
The LC connector is a high-performance fiber optic connector for singlemode and multimode applications, characterized by low insertion loss. It is one of the most common types of fiber optic connectors. The design of the LC connector is based on a single-fiber ceramic ferrule with a diameter of 1.25 mm for a light waveguide. Due to its compact design, the LC connector allows for high packing density, making it frequently used for fiber optic switches.
APC - Angled Physical Contact: Connectors with the APC designation have an end face that is not only rounded but also tilted a few degrees relative to the fiber axis. This design allows reflected light from the core to be refracted out into the air through the cladding, thereby preventing interference with data transmission.
Network cables
Quantity discount
CHF14.50 per piece for 2 units CHF7.26/1m
Lightwin FO patch cable LC/APC-LC/APC, singlemode, simplex, 2m
2 m
7. Lightwin Fiber optic patch cable LC-SC, multimode, OM4, 20m
The Lightwin LWL patch cable LC-SC is a high-quality fiber optic cable designed for multimode applications. With a length of 20 meters, it provides a reliable connection for various network and communication systems. The cable features an LC connector on one end and an SC connector on the other, allowing for flexible integration into existing systems. The fiber quality meets the OM4 standard, supporting high bandwidth and data transfer rates. This cable is suitable for both indoor and outdoor use, ensuring stable performance in different environments. Each cable is equipped with a serial number for easy identification and traceability. The Lightwin LWL patch cable is an excellent choice for anyone needing a reliable and high-performance fiber optic connection.
- Fiber quality according to OM4 standard for high bandwidth and data transfer rates
- Serial number on each cable for easy identification
- Suitable for indoor and outdoor applications
- Full duplex connection for simultaneous data transmission in both directions.
8. Lightwin LWL Duplex Patch Cable Multimode
Multimode E2000-LC OM4 15 m. Cable length: 15 m. Fiber quality: OM4. Connectors: E2000 - LC. Multimode fiber with a fiber diameter of 50/125 µm. A conventional electrical signal in a copper cable is disrupted by electromagnetic interference. In contrast, fiber optic cables offer better protection against interference and are also more secure against eavesdropping. Additionally, due to the low attenuation of fiber optic cables, long distances can be covered. E2000 connector: The E2000 connector is suitable for single-mode and multimode fibers and is characterized by its high data throughput. A special feature of the E2000 connector is a small flap that protects the user from escaping laser beams and the fiber end from dirt and damage. LC connector: The LC connector is a high-performance fiber optic connector for single-mode and multimode applications and is distinguished by its low insertion loss. It is one of the most common types of fiber optic connectors. The design of the LC connector is based on a single-fiber ceramic ferrule with a diameter of 1.25 mm for a fiber optic cable. Due to its compact design, the LC connector allows for high packing density, making it frequently used for fiber optic switches. OM4 classification: The OM designation for a fiber optic cable defines the quality class of a multimode fiber optic cable. The classification distinguishes four classes (OM1 to OM4). The distinction is made based on the level of optical attenuation and the possible transmission rate and distance. The fiber categories OM3 and OM4 are intended for high-speed applications such as (10/40/100-)Gigabit Ethernet or Fibre Channel at 850 nm. OM4-class multimode fibers have an Effective Modal Bandwidth (EMB) of 4.7 GHz x km.
9. Lightwin Fiber optic patch cable LSH/APC-LC, singlemode, duplex, 1m
Singlemode LSH/APC (compatible with E2000/APC) - LC Duplex OS2 1 m. Cable length: 1 m. Fiber quality: OS2. Duplex. Connectors: LSH/APC (compatible with E2000/APC) - LC. 2. 8 mm cable diameter (Figure 8), specially selected ferrule, serial number on each cable. LSOH flame-retardant jacket, measurement protocol for RL & IL, lifetime warranty by Lightwin Lifetime Warranty. LC connector. The LC connector is a high-performance fiber optic connector for singlemode and multimode applications, characterized by low insertion loss. It is one of the most common types of fiber optic connectors. The design of the LC connector is based on a single-fiber ceramic ferrule with a diameter of 1.25 mm for a fiber optic. Due to its compact design, the LC connector allows for high packing density, making it frequently used for fiber optic switches.
Network cables
CHF23.70 CHF23.70/1m
Lightwin Fiber optic patch cable LSH/APC-LC, singlemode, duplex, 1m
1 m
10. Lightwin Fiber optic patch cable LSH-LC, singlemode, duplex, 2m
All LIGHTWIN® fiber optic patch cables are processed with special ferrules and manufacturing methods to create a high-quality product. These cables are suitable for all fiber optic applications in various areas of telecommunications. Typical application areas include patching in data centers, server or network cabinets, as well as in FTTH (Fiber to the Home). By using single-mode ferrules for the LIGHTWIN® multimode patch cables and specially selected ferrules with minimal tolerances for the LIGHTWIN® single-mode patch cables, attenuation values are achieved that far exceed the required standards according to ISO/IEC.
Additional benefits of LIGHTWIN® fiber optic patch cables:
Main features:
- Cable length: 2 m
- Fiber type: OS2
- Connector 1: E-2000 (LSH)
- Connector 2: LC
- Connector 1 gender: Male
- Connector 2 gender: Male
- Product color: Blue, Yellow
- Jacket material: Low smoke halogen-free (LSZH)
- Hole diameter: 9 µm
- Coating diameter: 125 µm
- Cable mode structure: Single-mode
Technical details:
- Does not contain: Halogen
- Weight and dimensions: Cable diameter 2.8 mm
- Packaging data: Quantity 1.
Network cables
CHF25.70 CHF12.86/1m
Lightwin Fiber optic patch cable LSH-LC, singlemode, duplex, 2m
2 m
