Best Steinel products in the Motion sensors category
On this page you'll find a ranking of the best Steinel products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Steinel Is 240 Duo
Steinel Infrared Wall Sensor IS 240 Duo
Infrared wall sensor, white
Suitable for outdoor and indoor use
Switching capacity of up to 1000 W
240° detection range with a 180° opening angle
Range of up to 12 m
Wall or corner mounting
The Infrared Wall Sensor IS 240 Duo provides an optimal solution for monitoring large house fronts and outdoor corners with its 240° detection angle. Thanks to its two infrared detectors arranged at a special angle to each other, it can seamlessly monitor areas of up to 230 m². When mounted on outdoor corners, its wide detection angle allows it to cover a particularly large area, eliminating the need for a second sensor.
Easy installation
You can customize the detection area using the included cover caps as needed. The individual setting of the time and twilight threshold is made using an easily accessible rotary knob. Thanks to the spacious, clearly laid out connection area, you can install the IS 240 Duo quickly and easily on the wall or at the building corner. The power supply can be done either surface-mounted or flush-mounted.
Additional information
Color: White
Includes corner wall mount
Dimensions:
Dimensions 60 mm (W) x 90 mm (H) x 100 mm (D)
Depth: 100 mm
Height: 90 mm
Width: 60 mm
General
Product type: Motion detector
Additional functions: None
Detection angle: 240°
Detection range: 12 m
Sensor type: Passive infrared
Under-crawl protection: Yes
Time setting: 10 sec. - 15 min.
Mounting: Wall/corner mounting
Environmental conditions: Outdoor use: No
Operating temperature min.: -20 °C
Operating temperature max.: +50 °C
Protection class: IP54
Power: Input voltage: 230 V.

2. Steinel Is 140-2
Live comfortably while saving energy. Enjoy enhanced quality of life, safety, and energy savings through the intelligent sensor technology from STEINEL.
Light on/off – automatically. Highly innovative sensors respond to movements and light conditions, automatically turning the light on and off after a set time.
The IS 140-2 is considered a classic among infrared motion detectors. STEINEL has now enhanced this classic with even more features. With larger adjustable angles both horizontally and vertically for targeted detection around the house at a detection angle of 140°, increased range (up to 14 m), and more detection levels, the IS 140-2 allows for more comprehensive monitoring. The optical system is equipped with precise, spherical Fresnel lenses that enable more accurate person detection and consistently high range.
Adjustment options: Accurate customization of the detection area through the horizontally adjustable optical system (90°) and vertically (180°). Additionally, the detection area can be restricted using included cover plates. The IS 140-2 features simple adjustment of time and twilight threshold via a rotary knob located at the bottom of the sensor lens. Thanks to the spacious and clearly organized connection area, the infrared motion detector IS 140-2 can be wired easily and quickly, and mounted on a wall or corner – the suitable corner wall mount is available as an accessory. The connection can be made either surface-mounted or flush-mounted.

3. Steinel LED interior light RS 20 S
Circular classic. The perfect shape. The perfect efficiency. The perfect sensor ceiling light. The RS 20 LED integrates harmoniously into corridors, hallways, and staircases. It combines timeless design and easy installation with groundbreaking technology and maximum efficiency. Up to ten lights can be interconnected via cable. Power: 9.5 W with 960 lm, 3000 K.

4. Steinel Infrared sensor IS 345 COM1
Groundbreaking sensor technology. Targeted detection. Corridors and long hallways have specific requirements for sensor performance. The detection field of the sensor must be narrow yet long. This is the only way to effectively cover long sections with as few sensors as possible. The IS 345 is a proven specialist for such applications in indoor environments. It features a special corridor detection and a 45° opening angle, allowing it to monitor up to 20 x 4 meters tangentially.

5. Steinel Presence detector
The presence detector from Steinel is a highly advanced device designed for precise motion detection in large spaces. With a comprehensive detection range of 360 degrees and a coverage area of up to 576 m², this detector is ideal for use in open-plan offices, classrooms, and other expansive indoor environments. The wireless setup and networking via Bluetooth allow for easy integration into existing systems. The IR Quattro HD-2 is equipped with multiple individually controllable pyro-sensors, enabling flexible adaptation to various requirements. Additionally, the detector measures not only presence but also brightness, temperature, and humidity, making it a versatile tool for modern smart home applications. Installation can be done as either flush-mounted or surface-mounted, providing extra flexibility during setup.
- 360° detection with a range of up to 576 m²
- Individually controllable pyro-sensors
- Wireless setup and networking via Bluetooth
- Measurement of brightness, temperature, and humidity
- Compatible with smart home systems.

6. Steinel Infrared sensor IS 345 MX DALI
The specialist for high-bay warehouses and the highest monitoring quality. High-bay warehouses often have narrow aisles and very high ceilings, too high for most sensors. We have the perfect solution in our program: The infrared motion detector IS 345 MX Highbay has been specifically designed for mounting heights of up to 14 meters and for precise detection between narrow shelving aisles. Up there, it literally ensures monitoring quality at the highest level. In the future, you can confidently think in larger scales when it comes to sensor technology! Now also available in flush-mounted version.

7. Steinel 110078853
Steinel HF Presence Detector True Presence KNX-Upsw
Manufacturer: Steinel
Designation: HF Presence Detector UP
Type: True Presence KNX-Upsw
Bus System KNX: yes
Bus System KNX Wireless: no
Bus System Wireless Bus: no
Bus System LON: no
Bus System Powernet: no
Other Bus Systems: other
Bidirectional Wireless: yes
Execution: Presence Detector
Mounting Type: Flush-mounted
Material: Plastic
Material Quality: Thermoplastic
Surface Protection: other
Color: black
RAL Number (similar): 9005
Transparent: no
With Bus Coupling: yes
Secondary Input: yes
Creeping Protection/Return Field Monitoring: yes
Operating Mode Switch: yes
Adjustable Response Brightness: yes
Teach Function for Response Brightness: no
Self-learning Switch-off Delay: yes
Optimal Mounting Height: 2.8 m
Max. Range to One Side: 7.5 m
Max. Frontal Range: 7.5 m
Detection Field Diameter on Floor: 15 m
Vertical Detection Angle: 160 °
Horizontal Detection Angle: 360 °
Number of Channels: 4
Min. Switch-on Duration: 30 s
Max. Switch-on Duration: 1092 min
Steinel HF Presence Detector True Presence KNX-Upsw: additional details
The world's first true presence detector. No unnecessary after-run time, no unnecessary energy costs. 100 percent reliable detection through precise high-frequency measurement of the environment. The True Presence Detector reliably detects the presence or absence of individuals over an area of 64 m² by sensing micro-movements, such as the breathing-related rise and fall of the chest or shoulders. The new standard in building automation.
EAN: 4007841068516.

8. Steinel Presence detector bus DALI UP ws 360° v140° 002817
The DALI UP presence detector bus from Steinel is a highly modern motion sensor specifically designed for indoor use. With a detection angle of 360 degrees and a range of up to 6 meters, this presence detector provides comprehensive monitoring and ensures that light is only activated when truly needed. The HF sensor type allows for precise movement detection, saving energy and increasing efficiency. It is designed for flush mounting, enabling seamless integration into various environments. Additionally, the detector is compatible with Smart Home systems, allowing for easy control and adjustment of lighting. Made in Germany, the presence detector combines functionality and quality in an elegant glass design.
- 360° detection angle for comprehensive motion detection
- Range of up to 6 meters
- Flush mounting for discreet installation
- Compatible with Smart Home systems.

9. Steinel Presence detector IR Quattro MICRO
Requested by architects and planners, created by STEINEL. The IR Quattro MICRO fulfills many needs. Its small installation dimensions and low profile make it perfect for applications where intrusive installations on the ceiling are not desired. The micro-precision lens measures just 15 x 15 mm. Its performance is impressive despite its size. The 360° infrared presence detector covers an area of 36 m². Thanks to its IP65 certification, it can also be used in damp rooms. The IR Quattro MICRO - our smallest with great potential.

10. Steinel 086930
Steinel IR motion detector MD IR4360-24. Manufacturer: Steinel. Designation: IR motion detector AP. Type: MD IR4360-24. Sensor type: passive infrared. Optimum mounting height: 2.8 m. Max. range to one side: 12.5 m. Max. range frontal: 12.5 m. Detection field diameter on floor: 5 m. With remote control: no. Adjustable response sensitivity: no. Suitable for wall mounting: no. Mounting type: surface-mounted. Connection type: other. Material: plastic. Material grade: other. Antibacterial treatment: no. Transparent: no. Angle of detection horizontal: 360°.
Steinel IR motion detector MD IR4360-24: more details. Powerful 360° IR motion detector with Ø 8 or Ø 24 m range. With COM1 interface, push-button input, and full/semi-automatic mode. Reliable motion detection and light measurement, ideal for offices, meeting rooms, passageways, or larger areas. Available as flush-mounted, surface-mounted, or ceiling-recessed version. Setting and operation via Smart Remote remote control or potentiometer. Simple installation thanks to modular design. Installation height max. 4 m. Parallel connection possible (max. 10 sensors). Switching load: 2000 watts or 500 watts (LED). EAN: 4007841086930.
