WISI DRC 0524 FLEXSWITCH Multiswitch 5 DRC 0524

Wisi Multiswitch DRC 0524

Manufacturer: Wisi
Designation: Multiswitch 5in24, Cascadable TerrAktiv
Type: DRC 0524
Number of Subscriber Connections: 24
Number of Inputs: 5
Terrestrial Input: active
Cascadable: yes
Number of Main Outputs: 5
Max. Current Consumption: 305 mA
Power Supply: none
Control Signal: 14/18 V, DiSEqC, 0/22 kHz
LNB Power Supply: 12 V
22 kHz Generator: no

Wisi Multiswitch DRC 0524: additional details
The DRC 0524 is a cascaded multiswitch with 5 inputs for distributing satellite and terrestrial signals. The levels are available at 5 cascade outputs for subsequent multiswitches. The 24 subscriber outputs can operate standard DVB-S/S2 receivers or TVs with integrated receivers. Incoming terrestrial signals such as DVB-T/T2, DAB, or FM are also available at each subscriber output. The DRC 0524 impresses with low connection attenuation, achieved through the active terrestrial and SAT branches. The LNB power supply is ensured via upstream amplifiers or the optionally available power supply DRP 1533.
EAN: 4010056749569.
