Turck Opto-sensor

12 m
Ratings
BrandMore from Turck
Delivered between Wed, 13.8. and Wed, 3.9.

Product details

Turck Opto-Sensor Q20PRQ Manufacturer :Turck Designation :Opto-Sensor through-beam sensor Type :Q20PRQ Rated operating distance :12000 mm Max. Switching distance :12000 mm Electrical connection version :M8 plug connector Switching output version :PNP Switching function version :Changeover contact (NO/NC) Housing design :Cuboid Width of sensor :12 mm Diameter of sensor :0 mm Height of sensor :32 mm Length of sensor :20 mm Material of optical surface :Plastic Material of housing :Plastic Min. reflector distance :0 mm Reflector distance :0 mm Ambient temperature :-20...60 °C Response time :1 ms Switching frequency :600 Hz Wavelength of the sensor :655 nm Material of the cable sheath :Polyvinyl chloride (PVC) Suitable for safety functions :no Protection class (IP) :IP67 Turck Q20PRQ opto sensor: Further details Opto sensor, through-beam sensor (receiver), cable with plug connector, PVC, 150 mm, M8 x 1, 4-pin, degree of protection IP67, operating voltage: 10¿30 VDC, PNP switching output, changeover contact, LED visible all round, max. Range: 12000 mm , EAN: 0662488782238.

Key specifications

type of sensor
Optical
Range
12 m
Item number
36826520

General information

Manufacturer
Turck
Category
Motion sensors
Manufacturer no.
3078223
Release date
28.6.2023

Material

Material group
Plastic
Material
Plastic

Motion sensor properties

type of sensor
Optical
Range
12 m
Protection type (IP code)
IP67

Power supply

Output voltage
30 V

Smart home features

Smart Home
Not compatible

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 x
Scope of delivery
Opto-sensor

Product dimensions

Length
2 cm
Width
1.20 cm
Height
3.20 cm
