TracoPower DC/DC converter,9-36Vin,+/-15Vo 0.5A,15W

Ratings
BrandMore from TracoPower
Delivered Mon, 14.7.
7 pieces in stock at third-party supplier
Supplied by
Conrad CH
free shipping

Product details

Output voltage: ±15V DC
Input voltage: 9 to 36 V DC
Rated input voltage: 24 V DC
Insulation voltage: 1500V DC
Nominal power: 15W
Output current: ±500mA
Mounting type: Push-through mounting
Number of outputs: 2
Housing: DIP 24
Efficiency: 90%
Minimum temperature: -40°C
Maximum temperature: +85°C
Load balancing: ±1%
Network balancing: ±0.2%
Hum and interference voltage: 60mV

UL/cUL 60950-1, IEC/EN 60950-1 MTBF according to MIL-HDBK-217F at +25°C. Suitable common mode choke available. Regulated isolated DC/DC converter with single/double output from Traco, 15W series THD 15WIN. These converters feature high performance, shielded metal housing, and a wide input voltage range. They offer high efficiency and low input current under unloaded conditions. Typical applications include mobile devices, instrumentation, and distributed power architectures in communications and industrial electronics. DIP 24 metal enclosure, highest power density, wide input voltage range from 4:1, very high efficiency up to 90%, operating temperature range from -40°C to +85°C, I/O isolation of 1500 VDC, undervoltage interlock, short-circuit protection, input filter to EN 55022, Class A, and remote on/off with industry standard pin assignment.

Key specifications

input voltage
36 V
Output voltage
15 V
Power output
15 W
Voltage transformer type
Vehicle voltage transformer
Length
3.18 cm
Width
2.03 cm
Height
1.02 cm
Item number
9893445

General information

Manufacturer
TracoPower
Category
Power inverters
Manufacturer no.
THD 15-2423WIN
Release date
15.10.2018

Voltage Transformer Properties

Voltage transformer type
Vehicle voltage transformer
input voltage
36 V
Output voltage
15 V
Power output
15 W
Electric current output
0.50 A

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
3.18 cm
Width
2.03 cm
Height
1.02 cm
Weight
14.40 g
