Theben theRonda P360 KNX UP WH

Theben presence detector theRonda P360 KNX UPWH

Manufacturer: Theben
Designation: Presence detector
Type: theRonda P360 KNX UPWH
Bus system KNX: Yes
Bus system KNX radio: No
Bus system radio bus: No
Bus system LON: No
Bus system Powernet: No
Radio bidirectional: No
Design: Presence detector
Mounting type: Other
Material: Plastic
Material grade: Thermoplastic
Surface protection: Untreated
Finish: Matt
Color: White
RAL number (similar): 9010
Transparent: No
With bus coupling: Yes
Extension input: Yes
Creep protection/back field monitoring: No
Operating mode switch: No
Animal track: No
Staircase monitoring: Yes
Response brightness adjustable: Yes
Teach function for response brightness: Yes
Self-learning switch-off delay: Yes
Optimum mounting height: 3 m
Max. range to one side: 4 m
Range to one side: 4 m
Max. range frontal: 4 m
Detection field diameter on floor: 8 m
Detection angle horizontal: 0-360°
Number of channels: 4
Min. duty cycle: 30 s
Max. duty cycle: 60 min

Theben presence detector theRonda P360 KNX UPWH is a KNX presence detector for ceiling mounting. It features two channels for controlling two light groups, with options for switching or constant light control. The operation can be set to full or semi-automatic. It includes channel brightness with cyclic output, a channel for room monitoring, and the ability to shorten the overrun time for short presence. The detection area is round, and the light switch-off delay is adjustable and self-learning. The device allows switching between two brightness setpoints, which can be adjusted via the bus. It also has stand-by functionality, two presence channels with switch-on and switch-off delay, remote-controllable parameters, selectable master/slave operation, test functions, and scene control with two 8-bit scenes. Integrated bus coupler included.
