Theben Cheops S Knx

Theben actuator Cheops S KNX
Manufacturer: Theben
Designation: Actuator
Type: Cheops S KNX
Bus system KNX: Yes
Bus system KNX radio: No
Bus system radio bus: No
Bus system LON: No
Bus system Powernet: No
Radio bidirectional: No
Mounting type: Radiator valve
With bus coupling: Yes
Temperature controller with continuous control built-in: Yes
Buttons for manual operation on the actuator: No
Temperature and stroke display: Yes
Function master/slave: Yes
Bus voltage supply: Yes
Protection class (IP): IP21

Theben Cheops S KNX actuator: further details
Motorised KNX actuator for heating and cooling valves, integrated temperature sensor, integrated controller for efficient heating and cooling with one additional stage each, high actuating force with up to 220 N at a maximum valve stroke of 8 mm, 2 universal binary inputs, connection option for heating and cooling valves, external temperature sensor, window contact, presence detector or push-button, integrated logic for up to 10 window contacts, can be used in the heating circuit distributor, integrated bus coupler, automatic valve adaptation, universally applicable thanks to a large range of valve adapters, 2 different valve adapters for the most common valves M30x1.5 and Danfoss included (VA 10, VA 100), secure commissioning and communication through support of KNX Data Secure, EAN: 4003468730027.
