Industrial unmanaged PoE switch. Connections: 8x RJ45, 2x SFP. Number of PoE ports: 8, PoE standard: 802.3af/at, PoE 30 Watts, PoE budget: 240 W. Mounting: Desktop, DIN rail, wall. 8x PoE ports supporting 802.3af and 802.3at, 2x SFP ports for long-range fiber communication, 8x Gigabit Ethernet with speeds of up to 1000 Mbps. Total power budget at the PSE up to 240 W, robust aluminum housing. Options for DIN rail and surface mounting. Power over Ethernet (PoE). With Power over Ethernet, you can power compatible devices through the network cable. This significantly reduces cabling effort for end devices such as wireless access points, IP phones, and IP cameras, while providing high flexibility in device placement. 802.3at PoE. The IEEE 802.3at standard provides a maximum of 25.4 Watts of power per PoE port with a voltage of up to 50 Volts. The standard assumes that after line losses, 21.90 Watts of usable power remain to avoid exceeding the maximum power output. For PoE, a Cat5e/6 cable with a maximum length of 100 m is recommended.
Max. port speed | 1000 Mbit/s |
Network connections | SFP (2x) |
Switchtype | Desktop switch, DIN Rail Switch, PoE Switch |
Number of PoE ports | 8 ports |
Management | Unmanaged |
Switch functions | PoE |
Item number | 21065262 |
Manufacturer | Teltonika |
Category | Network switches |
Manufacturer no. | TSW200 |
Release date | 5.4.2022 |
Sales rank in Category Network switches | 348 of 5891 |
External links |
Colour | Black |
Exact colour description | Juoda |
Switchtype | Desktop switch, DIN Rail Switch, PoE Switch |
Number of ports | 10 ports |
Number of PoE ports | 8 ports |
PoE Standard | 802.3at (PoE+) |
PoE budget | 240 W |
Management | Unmanaged |
Switch functions | PoE |
switching layer | Layer 2 |
Switching capacity | 20 Gbit/s |
MAC adress table size | 2000 |
Manufacturer Type | TSW200 |
Network connections | SFP (2x) |
Max. port speed | 1000 Mbit/s |
Max. port speed RJ45 | 1000 Mbit/s |
Max. Port Speed Fiber | 1 Gbit/s |
Max. Port speed | 1000 Mbps / 1 Gbps |
Application range | Network |
Network operation | Power supply internal, Powered device |
Power consumption | 245.50 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Packaging box, Quick start guide, TSW200 |
Length | 9.51 cm |
Width | 13.20 cm |
Height | 4.42 cm |
Weight | 603 g |
Length | 18.80 cm |
Width | 15.40 cm |
Height | 7.10 cm |
Weight | 598 g |
