Synergy 21 Keystone, module, TP socketRJ45, CAT6A, 500MHz, slim-line, with cable clamp, Synerg

Module cutout size: h19.7/b14.8mm, AWG22-26, T568A/B labeling, installation height only 22mm, very compact design. Strain relief via cable clamp for the cable. L×W×H: 34.6×14.5×18.8mm. The high quality of the RJ45 Keystone module ensures excellent performance for 10 Gigabit Ethernet applications. No special tools are required. Assembly is quick and easy. With the RJ45 module, you receive a fully shielded module that will serve you well in your network installation for a long time.

Features:

• Cat.6A Permanent Link Test ISO 11801 (PL2) Class Ea 15M, 50M, 90M
• Compact cable sorter for AWG22-26
• Pair management according to TIA/EIA 568 A/B color codes (color code printed on the cable sorter)
• Suitable for patch panels and mounting rings with keystone cutouts

Product specifications:

• Category CAT6A
• Type Socket (Jack)
• Connection type IDC
• Connector type RJ45 8(8)
• Shielded Yes
• AWG range 22-26
• Suitable for round cables Yes
• Suitable for solid conductors Yes
• Housing material Zinc die-cast
• Max. cable diameter 5-8.5 mm
• Plug cycles = 750
• 360° shield contact Yes
• Strain relief No
• Temperature range -10 to +70 °C
• Insulation resistance = 500 MΩ
• ISO/IEC 11801:2002 Class EA
• ISO/IEC EN 50173 Class EA
• EIA/TIA 568-C Cat.6A
• IEC 60603-7-5
• Supports PoE per IEEE 802.3af, PoE+ per IEEE 802.3at.
