Siemens SIEM 5SV3647-6 RCD circuit breaker TYPE A 80/4 300MA 4TE

Siemens Dig.Industr. RCD 5SV3647-6

Manufacturer: Siemens Dig.Industr.
Description: Type A RCD, 300 mA, 80 A
Type: 5SV3647-6
Number of poles: 4
Rated voltage: 400 V
Rated current: 80 A
Rated residual current: 0.3 A
Mounting type: DIN rail
Residual current type: A
Selective type: no
Time-delayed type: no
Short-circuit strength (Icw): 10 kA
Surge current strength: 1 kA
Voltage type: AC
With locking device: yes
Frequency: 50 Hz
Additional devices possible: yes
Protection class (IP): IP20
Width in division units: 4
Installation depth: 70 mm
Ambient temperature during operation: -25..45 °C
Connectable conductor cross-section multi-stranded: 0.75..35 mm²
Connectable conductor cross-section single-stranded: 0.75..35 mm²
Explosion-proof: no

Siemens Dig.Industr. RCD 5SV3647-6: further details
RCD, 4-pole, Type A, In: 80 A, 300 mA, Un AC: 400 V
The SENTRON 5SV3 RCD provides comprehensive protection for people and property against electric shock. The RCDs offer reliable safety during installation due to the standard included gripping and touch protection. With the convenient slider manual operation, you can easily detach the RCDs from the DIN rail or busbar system without tools. The data matrix code on the device provides quick access to all technical data in the Siemens Industry Online Support App. The SENTRON protective devices can be expanded with a wide range of functions using the comprehensive accessories from the modular system. Optimal technology for your safety - only from Siemens.
EAN: 4001869427874.
