Siemens Circuit breaker UC C 63A 4p 400V 5SL4463-7

Ratings
BrandMore from Siemens
Delivered between Wed, 22.10. and Fri, 7.11.
free shipping

Product details

Siemens Dig.Industr. Circuit Breaker 5SL4463-7

Manufacturer: Siemens Dig.Industr.
Designation: Circuit breaker 400V, 10kA, 4p., C, 63A
Type: 5SL4463-7
Installation depth: 70 mm
Tripping characteristic: C
Number of poles (total): 4
Number of protected poles: 4
Rated current: 63 A
Rated voltage: 400 V
Rated breaking capacity Icn according to EN 60898 at 230 V: 10 kA
Voltage type: AC
Rated breaking capacity Icn according to EN 60898 at 400 V: 10 kA
Rated breaking capacity Icu according to IEC 60947-2 at 230 V: 10 kA
Rated breaking capacity Icu according to IEC 60947-2 at 400 V: 10 kA
Frequency: 50 Hz
Energy limitation class: 3
Flush-mounted: no
Switching neutral conductor: no
Overvoltage category: 3
Pollution degree: 2
Additional devices possible: yes
Width in division units: 4
Protection class (IP): IP20
Ambient temperature during operation: -25..55 °C
Connectable conductor cross-section multi-stranded: 0.75..25 mm²
Connectable conductor cross-section single-stranded: 0.75..25 mm²
Explosion-proof: no

Siemens Dig.Industr. Circuit Breaker 5SL4463-7: further details
Circuit breaker 400V 10kA, 4-pole, C, 63A
SENTRON 5SL circuit breakers provide safe short-circuit and overload protection for standard applications in residential and commercial buildings. Tool-free installation and removal of the device. Easy wiring of the supply through the rear-mounted busbar. The 5SL circuit breakers are available in 1-, 2-, 3-, 4-, as well as in 1+N and 3+N pole versions, along with other special types. A wide range of accessories, such as auxiliary switches, allows for versatile function expansion. Simply safe with SENTRON protection devices.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
70 mm
Width
4 mm
mounting style
Built-in
number of poles
4
Item number
32371971

General information

Manufacturer
Siemens
Category
Residual-current device
Manufacturer no.
5SL4463-7
Release date
7.12.2022

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Built-in
number of poles
4
Tripping characteristic
C
Rated current
63 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
400 V
Protection type (IP code)
IP20

Origin

Country of origin
Romania

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
4 mm
