Siemens Circuit breaker UC B 80A 4p 400V 5SP4480-6

Siemens Dig.Industr. miniature circuit breaker 5SP4480-6 Manufacturer :Siemens Dig.Industr. Designation :Miniature circuit breaker 4P, B-Char, In: 80A Type :5SP4480-6 Mounting depth :70 mm Tripping characteristic :B Number of poles (total) :4 Number of fused poles :4 Rated current :80 A Rated voltage :400 V Rated insulation voltage Ui :440 V Rated breaking capacity Icn according to EN 60898 at 230 V :10 kA Voltage type :AC Rated breaking capacity Icn to EN 60898 at 400 V :10 kA Frequency :50 Hz Flush mounting :no Switching neutral :no Overvoltage category :3 Degree of pollution :3 Additional devices possible :yes Width in pitch units :6 Protection class (IP) :IP20 Ambient temperature during operation :-25..55 °C Connectable conductor cross-section stranded :25..50 mm² Connectable conductor cross-section solid :25..50 mm² Explosion-proof :no Siemens Dig.Industr. miniature circuit breaker 5SP4480-6: more details Miniature circuit breaker 400V 10kA, 4-pole, B, 80A, T=70mm The miniature circuit breaker is the automatic circuit breaker for short-circuit protection. As an important part of the SENTRON protection components for electrical installations, the miniature circuit breakers from Siemens offer effective personal and system protection through safe disconnection in the event of an overload or short circuit. Convenient mounting and connection technology, uniform additional components and a consistent design - these are the hallmarks of the device family. Whether for infrastructure or for industrial requirements, Siemens offers miniature circuit breakers for all applications and every field of use. The Siemens miniature circuit breakers are characterised above all by: 1. effective personal, investment and system protection against overloads and short circuits. 2. a wide range of standardised accessories that are easy to install and can be replaced at any time. 3. reliable safety during installation thanks to the standard protection against contact and gripping. 4. clearly visible switch position indicator. 5. data matrix code on the front of the device provides quick and easy access to all information about the miniature circuit-breaker. Optimum technology for your safety - only from Siemens. , EAN: 4001869195568.
