Siemens 5SV3321-4

Ratings
Delivered between Tue, 1.7. and Wed, 9.7.
Only 2 items in stock at supplier

Product details

Siemens Digital Industry Residual Current Circuit Breaker 5SV3321-4

Manufacturer: Siemens Digital Industry
Designation: Residual Current Circuit Breaker Type B, 30 mA, 16 A
Type: 5SV3321-4
Number of Poles: 2
Rated Voltage: 230 V
Rated Current: 16 A
Rated Residual Current: 0.03 A
Mounting Type: DIN Rail
Residual Current Type: B
Selective Type: No
Short-time Delay Type: Yes
Short-Circuit Strength (Icw): 10 kA
Surge Current Strength: 3 kA
Voltage Type: AC
With Locking Mechanism: Yes
Frequency: 50/60 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Division Units: 4
Installation Depth: 70 mm
Ambient Temperature During Operation: -25..45 °C
Connectable Conductor Cross-Section Multi-stranded: 0.75..35 mm²
Connectable Conductor Cross-Section Single-stranded: 0.75..35 mm²
Explosion-Proof: No

Siemens Digital Industry Residual Current Circuit Breaker 5SV3321-4: Additional Details
Residual Current Circuit Breaker, 2-pole, Type B, short-time delayed, In: 16 A, 30 mA, Un AC: 230 V

The SENTRON 5SV3 Residual Current Circuit Breakers provide comprehensive protection for people and property against electric shock. These circuit breakers offer reliable safety during installation thanks to the standard integrated touch protection. With the convenient slider manual operation, you can easily detach the circuit breakers from the DIN rail or busbar connection without tools. The data matrix code on the device provides quick access to all technical data in the Siemens Industry Online Support App. The SENTRON protective devices can be expanded with a wide range of functions using the consistent accessories from the system modular kit. Optimal technology for your safety - exclusively from Siemens.
EAN: 4001869548869.

Key specifications

Circuit breaker type
Fault current circuit breaker
Length
70 mm
Width
4 mm
mounting style
Top-hat rail
number of poles
2
Item number
31989316

General information

Manufacturer
Siemens
Category
Residual-current device
Manufacturer no.
5SV33214
Release date
24.10.2022

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
mounting style
Top-hat rail
number of poles
2
Tripping characteristic
B
Rated current
16 A
Rated current
0.03 A
Rated voltage
230 V
voltage type
AC
Residual current (rated differential current)
0.03 A
Protection type (IP code)
IP20

Origin

Country of origin
Germany

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
4 mm

30-day right of return if unopened
24 Months Warranty (Bring-in)
