Shuttle AIO X5090PA /8GB/128GB SSD/Intel UHD/black
Intel Celeron 7305, 8 GB, 120 GBOnly 1 piece in stock at supplier
Product details
The Shuttle XPC all-in-one X50V9 is the new model in Shuttle's successful X50 series and is equipped with a Gen12/13 Intel ULV processor. The modern processor architecture has a very positive impact on power consumption and computing performance. The existing Wi-Fi function can optionally be enhanced with a 4G/5G feature with up to 4 antennas. Thanks to passive heat pipe cooling, the system is virtually silent, maintenance-free, and suitable for 24/7 continuous operation. Useful for applications in vertical markets, most of the ports are arranged on the underside of the chassis, and the front is resistant to dust and splashes according to protection class IP54.
PC type | All in One PC |
Processor family | Celeron |
Video connections | HDMI (1x) |
Exact USB ports | USB-A 3.2 Gen 2 (2x) |
Network connections | RJ45 (1x) |
Item number | 46457681 |
Colour | Black |
Exact colour description | Black |
PC type | All in One PC |
Operating system | Windows |
Operating system architecture | 64-bit |
Number of processors | 1 x |
Processor family | Celeron |
Processor type | Intel Celeron 7305 |
Clock frequency | 0.80 GHz |
Max. TDP | 55 W |
Number of processor cores | 2 -Core |
Number of performance cores | 1 -Core |
Number of efficiency cores | 4 -Core |
Number of threads | 2 |
Cache | 8 MB |
Processor cooling type | Passive (fanless) |
Memory | 8 GB |
Memory configuration | 1 x 8GB |
Max. supported memory | 64 GB |
Memory type | DDR4-RAM |
RAM speed | 2666 MHz |
Set clock frequency | 2666 MHz |
Memory form factor | SO-DIMM |
Number of memory slots | 2 |
Disk type | SSD |
Total capacity | 120 GB |
Form factor | M.2 |
SSD capacity | 120 GB |
Further data carrier type | SSD |
Graphics hardware | Integrated graphics |
Graphics card model | Intel UHD Graphics |
Number of graphics cards | 1 |
Graphics chip (GPU) | Intel UHD Graphics |
Graphics card cooling type | Passive (fanless) |
Max. Video resolution | 1366 x 768 pixels |
Max. port speed | 1000 Mbit/s |
Wireless transmission | Wi-Fi |
Bluetooth version | 4.2 |
Wi-Fi standard | Wi-Fi 5 / 802.11ac |
Chip | Realtek ALC888S |
Audio channel | Stereo |
"Number of 5.25"" drive slots" | 1 x |
"Number of 2.5"" drive slots" | 1 x |
Form factor | All-in-one |
USB ports | USB-A |
Exact USB ports | USB-A 3.2 Gen 2 (2x) |
Video connections | HDMI (1x) |
Network connections | RJ45 (1x) |
Optical drive type | No drive |
Memory card type | SD |
Power supply | 65 W |
Display size (inches) | 15.60" |
Image resolution | 1366 x 768 pixels |
Screen surface | Anti-glare |
Screen technology | LCD |
Display functions | Touch screen |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Length | 4.20 cm |
Width | 39.10 cm |
Height | 32.70 cm |
Weight | 3.50 kg |
