Schneider Electric Compact circuit-breaker

Schneider Electric moulded case circuit-breaker C11B3TM100B Manufacturer :Schneider Electric Designation :moulded case circuit-breaker ComPacT NSXm 100 A Type :C11B3TM100B Rated continuous current Iu :100 A Rated voltage :690 V Rated limit short-circuit breaking current Icu at 400 V, 50 Hz :25 kA Overload release Current setting :70...100 A Setting range of the instantaneous short-circuit release :1250 A Integrated earth fault protection :no Connection type main circuit :Screw connection Device type :Built-in device Fixed installation technology Suitable for top-hat rail mounting :yes Top-hat rail mounting optional :no With trip indicator :yes Number of poles :3 Position of connection for main circuit :Front actuator design :Toggle Complete device with protection unit :yes Integrated motor-drive unit :no Motor-drive unit optional :no Protection class (IP) :IP40 Schneider Electric moulded case circuit-breaker C11B3TM100B: further details This is a compact ComPacT NSXm circuit-breaker, 100 A, 25 kA at 415 VAC, for all LV standard applications. It offers new functions such as Everlink technology, DIN rail and panel mounting capability. It integrates new spring-type accessories that are externally visible. ComPacT NSXm is one of the smallest moulded case circuit breakers available on the market, 81 mm (W) x 137 mm (H) x 80 mm (D). This is a 3-pole version with an integrated thermo-magnetic tripping device. It ensures conformity with international standards (IEC 60947/CCC/EAC) and marine specifications. EAN: 3606481990334.
