Schneider Electric Circuit breaker NG125L, 3P, 50A, C 18805

Ratings
BrandMore from Schneider Electric
Delivered between Sat, 23.8. and Wed, 10.9.

Product details

Acti 9 NG125L circuit breaker, 50kA (IEC/EN 60947-2). 2-pole, rated current 50A, C-characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Protects the circuit against short-circuit currents and overload currents. The tripping is indicated by the middle position of the switch lever and a red mechanical display on the front of the device. Test button to check the tripping mechanism. Top or bottom feed. Jump switching for low-wear contact switching. Tripping unit technology: thermomagnetic. Additional snap-on auxiliary modules (optional): indication of switching position, fault tripping, working current tripping, undervoltage tripping, overvoltage tripping. The NG125L circuit breaker complies with the following standards: IEC/EN 60947-2.

Key specifications

Circuit breaker type
Circuit breaker
Width
4.50 mm
mounting style
Top-hat rail
number of poles
3
Item number
23347907

General information

Manufacturer
Schneider Electric
Category
Residual-current device
Manufacturer no.
18805
Release date
7.12.2022

Circuit Breaker Features

Circuit breaker type
Circuit breaker
mounting style
Top-hat rail
number of poles
3
Tripping characteristic
C
Rated voltage
415 V
voltage type
AC/DC
Rated insulation voltage Ui
690 V
Protection type (IP code)
IP20

Origin

Country of origin
France

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Schneider Electric fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Width
4.50 mm

30-day right of return if unopened
24 Months Warranty (Bring-in)
