Schneider Electric C25W3MA150 Compact circuit-breaker ComPacT NSX250HB2

Schneider Electric Compact circuit-breaker C25W3MA150 Manufacturer :Schneider Electric Designation :Compact circuit-breaker ComPacT NSX250HB2 Type :C25W3MA150 Setting range of instantaneous short-circuit release :1350...2100 A With thermal protection :no Phase loss sensitive :no Tripping mechanism :magnetic Rated operational voltage :690 V Rated uninterrupted current Iu :150 A Type of connection main circuit :screw connection Type of operating mechanism :other Type of device :built-in device Fixed mounting technology With integrated auxiliary contact :no With integrated undervoltage release :no Number of poles :3 Degree of protection (IP) :IP40 Height :161 mm Width :105 mm Depth :86 mm Schneider Electric compact circuit-breaker C25W3MA150: more details This ComPacT NSX250HB2 is a complete 3P 3d fixed-mount circuit-breaker designed to optimise space requirements and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (Icu) is 100 kA rms at 500 VAC 50/60 Hz and 100 kA rms at 690 VAC 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product contains a magnetic trip unit (MA) with a rated capacity of 150 A. The MA release provides adjustable magnetic protection for instantaneous tripping. This 3-pole version (105 mm x 161 mm x 86 mm) is supplied with a wide range of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX250HB2 is part of Schneider Electric's EcoStruxure Power architecture. , EAN: 3606482002500.
