Schneider Electric C25B3TM200 ComPacT NSX250B moulded case circuit-breaker with

Schneider Electric Compact Circuit Breaker C25B3TM200

Manufacturer: Schneider Electric
Designation: Compact Circuit Breaker ComPacT NSX250B with Type: C25B3TM200
Rated Continuous Current Iu: 200 A
Rated Voltage: 690 V
Rated Short-Circuit Breaking Capacity Icu at 400 V, 50 Hz: 25 kA
Overload Relay Current Setting: 175..250 A
Setting Range of Short-Time Delay Short-Circuit Release: 1000..2000 A
Setting Range of Instantaneous Short-Circuit Release: 1000..2000 A
Integrated Earth Fault Protection: no
Connection Type for Main Circuit: Screw Connection
Device Design: Built-in Device Fixed Installation Technology
Suitable for DIN Rail Mounting: no
DIN Rail Mounting Optional: no
With Trip Indicator: no
Number of Poles: 3
Position of Connection for Main Circuit: Front
Design of Operating Element: Toggle Lever
Complete Device with Protection Unit: yes
Integrated Motor Drive: no
Optional Motor Drive: yes
Protection Class (IP): IP30

Schneider Electric Compact Circuit Breaker C25B3TM200: Additional Details
The ComPacT NSX250B is a complete 3P 3d circuit breaker in fixed installation, designed to optimize space requirements and breaking capacity. It is an optimal choice for all standard and special applications. The breaking capacity (Icu) is 25 kA effective at 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product features a thermal-magnetic release device (TMD) with a rated capacity of 200 A. The TMD release device provides adjustable thermal overload protection and fixed magnetic protection. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional functions and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. The ComPacT NSX250B is part of Schneider Electric's EcoStruxure Power architecture.
