Schneider Electric C11E3TM100L ComPacT NSXm 100 A moulded-case circuit-breaker

Schneider Electric moulded case circuit-breaker C11E3TM100L

Manufacturer: Schneider Electric
Designation: Moulded case circuit-breaker ComPacT NSXm 100 A
Type: C11E3TM100L
Rated continuous current Iu: 100 A
Rated voltage: 690 V
Rated limit short-circuit breaking current Icu at 400 V, 50 Hz: 16 kA
Overload release current setting: 70...100 A
Setting range of the instantaneous short-circuit release: 1250 A
Integrated earth fault protection: No
Connection type main circuit: Screw connection
Device type: Built-in device
Fixed installation technology
Suitable for top hat rail mounting: Yes
Top hat rail mounting optional: No
With trip indicator: Yes
Number of poles: 3
Position of the connection for main circuit: Front
Actuator design: Toggle
Complete device with protection unit: Yes
Integrated motor-drive unit: No
Optional motor-drive unit: No
Protection class (IP): IP40

This is a compact ComPacT NSXm circuit-breaker, 100 A, 16 kA at 415 VAC, for all standard LV applications. It offers new functions such as Everlink technology, DIN rail and panel mounting capability. It integrates new spring-type accessories that are externally visible. ComPacT NSXm is one of the smallest moulded case circuit breakers available on the market, measuring 81 mm (W) x 137 mm (H) x 80 mm (D). This is a 3-pole version with an integrated thermo-magnetic tripping device. It ensures conformity with international standards (IEC 60947/CCC/EAC) and marine specifications.
