Schneider C10F3

Ratings
BrandMore from Schneider
Delivered between 29.1.2026 and 12.2.2026
free shipping

Product details

Schneider Electric Compact Circuit Breaker C10F3

Manufacturer: Schneider Electric
Designation: Compact Circuit Breaker ComPacT NSX100F
Type: C10F3
Rated Continuous Current Iu: 100 A
Rated Voltage: 690 V
Rated Short-Circuit Breaking Capacity Icu at 400 V, 50 Hz: 36 kA
Integrated Earth Fault Protection: no
Connection Type for Main Circuit: Screw connection
Device Design: Built-in device with fixed installation technology
Suitable for DIN Rail Mounting: no
DIN Rail Mounting Optional: yes
With Trip Indicator: yes
Number of Poles: 3
Position of Connection for Main Circuit: front
Actuating Element Design: Knob
Complete Device with Protection Unit: no
Integrated Motor Drive: no
Optional Motor Drive: yes
Protection Class (IP): IP40

Schneider Electric Compact Circuit Breaker C10F3: additional details
This is a 3-pole main switch for ComPacT NSX100F. ComPacT NSX is designed to optimize space and breaking capacity for all standard and special applications. This main switch is delivered without a trip unit and is compatible with all types of trip units that can be ordered separately. The breaking capacity Icu is 36 kA at 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz (limited to 440 VAC 50/60 Hz when differential current protection is present). It can be equipped with a variety of optional features and accessories. The dimensions are 105 mm x 161 mm x 86 mm. It ensures compliance with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX100F is part of Schneider Electric's EcoStruxure Power architecture.

Key specifications

Circuit breaker type
Circuit breaker
Mounting type
Built-in installation
Width
105 mm
Length
161 mm
number of poles
3
Item number
31978176

General information

Manufacturer
Schneider
Category
Residual-current device
Manufacturer no.
C10F3
Release date
24.10.2022

Colour

Colour
Green
Exact colour description
Green

Circuit Breaker Features

Circuit breaker type
Circuit breaker
Mounting type
Built-in installation
Mounting type
Screw fastening
number of poles
3
Tripping characteristic
Sluggish ---
Rated current
100 A
Rated voltage
690 V
voltage type
AC
Protection type (IP code)
IP40

Origin

Country of origin
Poland

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
161 mm
Width
105 mm
Height
86 mm
