Satel Detector Universal/White Xd-2

Satel XD-2 Universal Detector, White

The XD-2 is a wired universal detector that is compatible with any alarm control panel. It can be used as a magnetic contact, shock sensor, shock sensor with magnetic contact, or water detector.

The detector is available in white, brown, and dark gray.

• Selection of detector type using DIP switches

• Operating modes:

• Magnetic contact:
• Detection of door and window openings, etc.
• Input for connecting a wired NC type detector
• 1 alarm output

• Shock sensor:
• Detection of shocks and vibrations that occur during attempted break-ins of doors or windows
• 1 alarm output

• Shock sensor with magnetic contact:
• Detection of shocks and vibrations that occur during attempted break-ins of doors or windows
• Detection of door and window openings, etc.
• 1 or 2 alarm outputs

• Water detector:
• Detection of water leakage in rooms with water installations
• Input for connecting an external water probe (probe sold separately)
• 1 alarm output

• LED for signaling
• Remote control for turning the LED signaling on/off
• Monitoring of power supply
• Tamper protection against opening the housing and detaching from the mounting surface
• 2 magnets included (for surface and flush mounting).
