Ruijie RG-EG305GH-P-E - Reyee router with PoE

Reyee RG-EG305GH-P-E Router with PoE

Manufacturer: Ruijie Networks
Code: 17800016
Part No: RG-EG305GH-P-E

Product Description:
The Reyee RG-EG305GH-P-E is a wired Gigabit router with PoE, designed to provide sufficient VPN performance for branch offices and remote workers in enterprises. It features secure and reliable web management, along with the ability to manage via Ruijie Reyee Cloud from anywhere. The router includes content blocking based on application type, intelligent multi-WAN load balancing, and supports up to 4 WAN ports simultaneously. It offers 1 Gigabit WAN port, 1 Gigabit LAN port, and 3 Gigabit LAN/WAN ports, with a total NAT performance of 1.5 Gbps and 802.3af/at PoE on the first 4 ports, providing a total PoE budget of 60W. The router also supports several VPN server options, including IPsec, PPTP, L2TP, and OpenVPN.

VPN Limits:

• IPsec: 230 Mbps, max. 64 tunnels
• L2TP: 640 Mbps, max. 64 tunnels
• OpenVPN: 100 Mbps, max. 64 tunnels

Package Contents:

• Device
• Power supply 54V / 1.48A
• Mains cable
• Product is only for the EU region

Technical Parameters:

Connections and Interfaces:

• WAN speed: (1) 10/100/1000 Mbps
• Multiple WAN: Yes
• LAN speed: (1) 10/100/1000 Mbps + (3) 10/100/1000 Mbps LAN/WAN
• Gigabit LAN: Yes

Power Supply:

• Power supply type: DC connection
• PoE type: PoE-Out (only)
• PoE-Out standards: 802.3af, 802.3at
• PoE outputs: 4
• PoE budget [W]: 60
• Max. Power consumption [W]: 80
• Power supply via connection/terminal: 54V / 1.5A

Physical Properties:

• Design: Desktop
• Fan: Without fan
• Housing design: Metal
• Buttons: Reset
• Operating temperature [°C]: 0 to 40
• Width [mm]: 202
• Height [mm]: 28
• Depth [mm]: 108

Hardware:

• CPU frequency [MHz]: 1350
• CPU cores: 2
• RAM [MB]: 512

General:

• NAT throughput [Mb/s]: 1500
• IPsec VPN throughput [Mb/s]: 230

Software:

• Supported VPN: PPTP, L2TP, IPSec, OpenVPN
• Web management: Yes
• Management: Web management, Ruijie cloud
• IPv6 support: Yes
• Default IP address:...
