RECOsystems Binding device WB 6 R (round hole)

Binding machine RECOsystems WB 6 R (round hole)

Professional, manual wire binding machine for wire comb binding with 4 mm round hole punching. The RECOsystems WB 6 R is the optimal punching and binding machine for office, copy store, and print store. Whether you need to quickly bind a brochure for a meeting in the office or want to produce a job of several hundred pieces, this sturdy machine allows you to easily bind a high-quality brochure. The WB 6 R is also ideally suited for larger runs.

Solid construction made of die-cast aluminum, with a housing completely made of sheet steel.

Technical data:

• Punching and binding width: up to A4+ (open at the side)
• Max. punching thickness: approx. 25 sheets (70/80 g/m²)
• Max. binding thickness: up to approx. 135 sheets (70/80 g/m²) for wire comb with 34 rings on A4 (pitch 3:1)
• For wire diameter 4.8 mm - 16.0 mm (3/16" - 5/8")
• Size of punching hole: 4 mm round hole
• Adjustable edge distance
• Adjustable punching depth
• Individually deactivatable punching
• Magnetic bar for support during binding process
• Two hanging devices
• Weight: 18.9 kg
• Dimensions: 520 x 500 x 380 mm.
