Qotom Mini PC Q310G4 S05

With the powerful Intel Core i5 processor and 4x Intel 1GbE, the Qotom Mini PC Q355G4 can be configured as a firewall, LAN or WAN router, VPN appliance, DHCP server, DNS server, and more. Small, quiet, compact, and affordable, running 24/7, the Qotom Firewall Appliance is a great solution for home, office, factory, and more.

Operating System
The Mini PC Q3xxG4 supports Windows, Linux, pfSense, Sophos, VyOS, Linux iptables, Untangle, and more. You can also install the operating system and software packages yourself. The F11 key boots from the USB drive. The Delete key accesses the BIOS.

QOTOM Firewall Appliance
With the powerful Intel processor and 4 x Intel 1GbE, the Qotom Mini PC can be configured as a firewall, LAN or WAN router, VPN appliance, DHCP server, DNS server, and more. Small, quiet, compact, and affordable, it runs 24/7. The Qotom Firewall Appliance is a great solution for home, office, factory, and more.

SIM and 3G/4G Module
There is a SIM slot on the motherboard, but the half Mini-PCI slot by default supports the Wi-Fi module. If you want to install a 3G/4G module, the screw must be removed to create a full Mini-PCI slot for it. We do not supply 3G/4G modules.

Description

• CPU: Intel Celeron Broadwell SOC processor, standard 3215U Quad-Core 2M Cache, 1.7 GHz, 15W
• Memory: Single Channel DDR3L 1333/1600MHz SDRAM, maximum 8G
• Chipset: As per CPU
• Display: Intel HD Graphics, 1 x HDMI
• Ethernet: 4 x Intel I211-AT Gigabit LAN, 1 x Mini PCIE, half-length for Wi-Fi module, full-length for 3G/4G module
• Audio: Realtek ALC662 HD Audio
• Storage: 1 x mSATA, 1 x SATA 3.0
• USB: 2 x USB 3.0, 2 x USB 2.0
• Serial: 2 x RS-232
• WatchDog: Yes
• GPIO: Yes
• RS-485: 0
• Power On: Yes

Front I/O

• Power Button: 1
• Serial Port: 1 x RS-232
• Display: 1 x HDMI
• USB: 2 x USB...
