Poynting A-PATCH-0025-V2-02 - PATCH-25 Circular polarised RFID patch antenna, 860-960 MHz, 8.7...
Delivered between Fri, 25.7. and Wed, 6.8.
Supplied by
Ultimus CH
free shipping
Product details
The PATCH-25 antenna covers both the EU and USA RFID bands. The antenna is waterproof and easy to install. It is circularly polarized and can be read in any orientation. Due to its circular polarization, it can also be used to enhance GSM coverage indoors. The VSWR is typically below 1.3:1, resulting in a return loss of more than 20 dB. This antenna is unique in the RFID environment due to its VSWR and gain specifications.
Antenna type | WLAN Antenna |
Antenna connection | N-Type |
Cable length | 3 m |
Application range | Indoor, Outdoor |
Protection type (IP code) | IP65 |
Operating temperature | -20 - 70 °C |
Item number | 30166718 |
Manufacturer | Poynting |
Category | Network antenna |
Manufacturer no. | A-PATCH-0025-V2-02 |
Release date | 25.4.2023 |
Antenna type | WLAN Antenna |
Antenna gain | 8.80 dBi |
Antenna connection | N-Type |
Cable length | 3 m |
Application range | Indoor, Outdoor |
Protection type (IP code) | IP65 |
Operating temperature | -20 - 70 °C |
CO₂-Emission | |
Climate contribution |
Length | 0.25 m |
Width | 0.25 m |
Height | 0.04 m |
Weight | 570 g |
