Moxa SFP-1GLSXLC-T - SFP module with 1 1000BaseLSX port with LC connector for 1km2km transmission

Moxa's Small Form-Factor Pluggable Transceiver (SFP) Ethernet fibre optic modules for Gigabit Ethernet provide coverage over a wide range of communication distances.

SFP module with 1 1000BaseLSX port with LC connector for 1km/2km transmission, -40 to 85°C operating temperature

Ethernet interface
ports

• 1

ports

• Duplex LC connector
• Simplex LC connector (WDM type only)

fibre

• Typical distance: To achieve the typical distance of the specified fibre transceiver, please refer to the formula: Link budget(dB) undgt; Scattering loss(dB) + Total loss(dB)

Performance parameters
Power consumption

• Max. 1 W

Ambient conditions
Operating temperature

• -40 to 85°C (-40 to 185°F)

Storage temperature (in packaging)

• -40 to 85°C (-40 to 185°F)

Relative humidity

• 5 to 95% (non-condensing)

Standards and certifications
Safety

• UL 62368-1
• IEC 62368-1
• IEC 60825-1

EMC

• EN 55032/35

EMI

• FCC 15B Test Report
• ICES-003: 2020 Edition 7

EMS

• IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
• IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
• IEC 61000-4-4 EFT: Power: 1 kV(AC), 0.5 kV(DC); Signal: 0.5 kV
• IEC 61000-4-5 Surge: Power: 1 kV / 2 kV(AC), 0.5 kV(DC); Signal: 1 kV
• IEC 61000-4-6 CS: 0.15 MHz to 10 MHz: 3 V, 10 MHz to 30 MHz: 3 to 1 V, 30 MHz to 80 MHz: 1 V
• IEC 61000-4-8 PFMF: 1 A/m at 50 Hz
• IEC61000-4-11 Voltage dips and interruptions

Maritim

• DNV.
