Moeller Electric 10kA Double Pole Type C MCB 16A

Range: xPole
Series: PLSM
Number of poles: 2
Rated current: 16 A
Tripping characteristic: Type C
AC rated voltage: 230 V AC
DC rated voltage: 48 V
Breaking capacity: 10 kA
Length: 35 mm
Width: 80 mm
Depth: 75 mm

The PLSM MW series is a type C, 2 pole miniature overload switch. It is versatile, safe, and of high quality, suitable for both commercial and residential use. The contact position indicator is red-green, providing guidance for safe connection. It features DIN rail mounting with 3 positions, allowing for the expansion of existing busbar systems. The rated currents go up to 63 A, with a rated breaking current of 10 kA according to IEC/EN 60898-1. It meets insulation coordination requirements, with a distance between contacts of ≥ 4 mm for safe disconnection.
