MeanWell DC/DC Converter Modules RDDW20 Series DIP/DIL x1 Case Dual Output 1 Railway

Ratings
BrandMore from MeanWell
Delivered the day after tomorrow
Only 2 pieces in stock at third-party supplier
Supplied by
Conrad CH
Free shipping starting at 50.–

Product details

The MeanWell RDDW20F-12 is a powerful DC/DC converter specifically designed for applications in the railway sector. With an output power of 20 watts and a maximum output voltage of 12 V, this module provides a reliable power supply for various electronic devices. The converter is housed in a compact DIP/DIL 2x1 inch package, allowing for direct mounting on circuit boards. Thanks to its wide input voltage range of 9 V to 36 V and high efficiency of up to 90%, the RDDW20F-12 is versatile and suitable for demanding environments. Additionally, it offers comprehensive protection features, including short circuit, overload, and overvoltage protection, ensuring the safety and longevity of the device. Weighing only 35 g, the converter is lightweight and compact, making it ideal for space-critical applications.

  • Input voltage ratio of 4:1
  • Input/output isolation of 1500 V DC
  • Operating temperature range of -40 °C to +85 °C
  • No minimum load required
  • Protection features against short circuit, overload, and overvoltage.

Key specifications

input voltage
36 V
Output voltage
12 V
Power output
20 W
Voltage transformer type
Vehicle voltage transformer
Length
5.08 cm
Width
2.54 cm
Height
1.02 cm
Item number
12970831

General information

Manufacturer
MeanWell
Category
Power inverters
Manufacturer no.
RDDW20F-12
Release date
22.3.2020

Voltage Transformer Properties

Voltage transformer type
Vehicle voltage transformer
input voltage
36 V
Output voltage
12 V
Power output
20 W
Electric current output
0.84 A

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
5.08 cm
Width
2.54 cm
Height
1.02 cm
Weight
35 g
