Product details
The MeanWell DC/DC converter is a reliable device designed for mounting on DIN rails. With an input voltage range of 9 to 18 VDC and a stable output voltage of 12 V, this voltage converter offers a nominal power of 99.6 W and a maximum output current of 8.3 A. It is ideal for applications that require precise voltage adjustment. The converter features a high efficiency of 88.5% and can operate within a wide temperature range of -40 °C to 70 °C. The aluminum housing ensures a robust construction, while integrated protection mechanisms such as overload protection and overvoltage protection guarantee the safety of the device. With a mean time between failures (MTBF) of 214,500 hours, this converter is a durable solution for various applications.
- Adjustable output voltage between 9 V and 14 V
- Operating temperature range of -40 °C to 70 °C
- High efficiency of 88.5%
- Integrated protection mechanisms such as overload and overvoltage protection
- Durable construction with an MTBF of 214,500 hours.
input voltage | 9 V |
Output voltage | 12 V |
Power output | 99.60 W |
Voltage transformer type | Vehicle voltage transformer |
Length | 14.50 cm |
Width | 13 cm |
Height | 5.50 cm |
Item number | 52637172 |
Manufacturer | MeanWell |
Category | Power inverters |
Manufacturer no. | DDR-120A-12 |
Release date | 5.11.2024 |
Voltage transformer type | Vehicle voltage transformer |
input voltage | 9 V |
Output voltage | 12 V |
Power output | 99.60 W |
Electric current output | 8.30 A |
CO₂-Emission | |
Climate contribution |
Length | 14.50 cm |
Width | 13 cm |
Height | 5.50 cm |
Weight | 510 g |
