LevelOne GSW-1657: 16Port Switch, 1Gbps

GSW-1657 16-Port Gigabit Switch

The GSW-1657 is a 16-port Gigabit Ethernet switch (10/100/1000 Mbps) that provides a high-performance and easy-to-use solution for expanding your network. The GSW-1657 features a non-blocking switching architecture that filters and forwards packets at full speed to ensure maximum data throughput. Additionally, this switch offers MAC address auto-learning and auto-aging, IEEE 802.3x flow control for full duplex, and backpressure for half duplex.

No configuration is required for the GSW-1657. With automatic MDI/MDI-X cable detection on all ports, there is no need for crossover cables or uplink ports. Each port can thus be used as a regular port or an uplink port.

Key Features:

• Complies with IEEE802.3, IEEE802.3u, and IEEE802.3ab
• 16 x 10/100/1000 Mbps N-way ports
• Auto-MDI/MDI-X uplink detection on all ports
• Full wire-speed packet filtering and forwarding
• Supports back pressure and flow control
• Store-and-forward architecture
• 1 fan

Connections:

• 16 x RJ-45 Gigabit Ethernet ports
• 1 x IEC-60320 C14 power inlet

Included in the box:

• Power cable
• 19" mounting brackets
• Grounding wire.
