Kemo PROsolar-1800 Inverter

The KEMOT PROsolar-1800 solar energy converter with an output power of 1800 W enables functionality for working with photovoltaic modules and the power grid. After connecting the solar panels, the device utilizes solar energy for appliances connected to the existing power grid. It is also suitable for powering electrical devices that require an alternating voltage of 230 V and ensures uninterrupted operation of devices that need a continuous power supply, such as central heating pumps, alarm, or surveillance systems. The KEMOT PROsolar-1800 features a robust housing with a mounting bracket that allows for wall installation, for example, in a boiler room or power plant.

Specifications:
Power: 1800 W
Battery Voltage: 24 VDC
Operating Mode: PV (photovoltaic priority) / AC (AC priority)
PV: Input Voltage Range: 30 VDC – 50 VDC
Max. Charging Current: 40 A (depending on the connected photovoltaic cell)
Max. Efficiency: 98%
AC: Input Voltage Range: 200 VAC ~ 275 VAC
Frequency Range: 45–65 Hz
Output Voltage Range: 206 VAC ~ 242 VAC
Input Power Factor (AC/DC): 98%
Efficiency: Grid Mode >= 96%
Charging Current: 10 A
Inverter Output:
Output Voltage: 230 V +/- 3%
Frequency: 50 Hz / 60 Hz +/- 0.3 Hz
Output Power Factor >= 0.8
Waveform Distortion: Linear Load = <3%
PV-AC Transfer Time: 4 ms typical value, max. 6 ms
Efficiency: Inverter Mode >= 80%
Inverter Overload: 110%–130% off in 30 s, 130%–150% off in 3 s
Ambient Temperature: 0–40 °C
Ambient Humidity: 10%–90%
Noise = <50 dB
Weight: 12.55 kg
Dimensions: 31 x 16 x 27 cm.
