Helos FTTH connection set, pre-assembled with LC-APC connectors on both sides, 50m

Helos FTTH connection set, OS2 4-fibre, pre-assembled on both sides with 4 LC-APC connectors each. The compact FTTH connection set is pre-assembled on both sides, eliminating the need for time-consuming connector installation. This installation is ideal for a fast high-speed fibre optic connection within the building and is available in various lengths and versions.

Short installation time: The fibre optic cable is quickly laid in the right place thanks to the one-sided pull-in aid. No more time-consuming splicing of the fibre optic connectors is required.

Technical details:

• 4-core installation cable OS2 9/125, G657.A2 LSZH
• Fire protection class: CPR B2ca s1a d0.a1
• Strain relief
• Adapter type: 2 x LC/APC Duplex
• Connector type: 8 x LC/APC
• Cable construction: I/A-V(Q(ZN)H
• Standards: IEC 61300-3-4, IEC 6130-3-6
• Cable: G657.A2 4C 250um Yellow Green Blue Red with KEVLAR Jacket
• LSZH OD: 2.2mm
• Colour: white

Technical details:

• Junction Box 2 LC/APC Duplex Couplers
• Laser Protection Wall Mounting
• RoHS 3.0 and REACH Compliant
• Temperature: -40 to +75
• Max 8 cores (Crimping Type)
• ABS Material UL94V2
• Colour: white
• Dimension: 80 x 80 x 28 mm.
