Hagor VWH-3 - Mounting kit (wall mount) for flat panel display - Black - Screen
Wall, 55", 70 kgOnly 4 items in stock at supplier
Product details
The Touch Lift Pro is a mobile stand system with electric height and tilt adjustment for a touchscreen or flat screen measuring between 55 and 84 inches. The height of the high-quality aluminum lift column can be adjusted by 500 mm using a remote control. The tilt angle of the mounting system can also be adjusted continuously via remote control between 0° and 90° (table position). Please note that not every screen is allowed to be tilted to 90° - be sure to check with the device manufacturer beforehand! The screen can be mounted using a VESA universal bracket, accommodating VESA standards from 75x75 to 800x600 mm. The high-quality casters allow for smooth mobility of the system. Additionally, the Touch Lift Pro can be secured in place with the integrated locking brakes. The base is designed to allow easy access to the Touch Lift Pro without tripping hazards. The load limit is a maximum of 120 kg.
VESA wall mount | 200 x 200 mm, 300 x 300 mm, 400 x 400 mm, 600 x 400 mm, 800 x 400 mm |
TV Wall Mount Features | Height-adjustable |
Max. screen diagonal (inch) | 55" |
Max. Wall distance | 10.50 cm |
Installation place | Wall |
Max. load | 70 kg |
Number of monitors | 1 |
Item number | 17710140 |
Manufacturer | Hagor |
Category | TV mounting solutions (universal) |
Manufacturer no. | 1484 |
Release date | 5.5.2021 |
Colour | Black |
Exact colour description | Black / Blue |
Material group | Metal |
Material | Metal |
Installation place | Wall |
TV Wall Mount Features | Height-adjustable |
VESA wall mount | 200 x 200 mm, 300 x 300 mm, 400 x 400 mm, 600 x 400 mm, 800 x 400 mm |
Max. screen diagonal (inch) | 55" |
Min. screen diagonal (inch) | 42" |
Max. Screen diagonal (cm) | 140 cm |
Min. screen diagonal (cm) | 107 cm |
Max. load | 70 kg |
Max. Wall distance | 10.50 cm |
Min. wall distance | 9.10 cm |
Number of monitors | 1 |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1 piece |
Length | 104 mm |
Width | 570.70 mm |
Height | 543.10 mm |
Depth | 104 mm |
Weight | 11500 g |
