Hager MCS310. Rated current: 10 A. Type: C-type, Module quantity (max): 3 module(s). Width: 52.5 mm

Ratings
Delivered between Sat, 5.7. and Tue, 15.7.
10 items in stock at supplier
Free shipping starting at 50.–

Product details

Hager Circuit Breaker MCS310

Manufacturer: Hager
Designation: Circuit breaker 3p, C-10A, 6kA, 3M QC
Type: MCS310
Installation depth: 70 mm
Tripping characteristic: C
Number of poles (total): 3
Number of protected poles: 3
Rated current: 10 A
Rated voltage: 400 V
Rated insulation voltage Ui: 500 V
Rated impulse voltage withstand Uimp: 4 kV
Type of voltage: AC
Rated switching capacity Icn according to EN 60898 at 400 V: 6 kA
Frequency: 50-60 Hz
Energy limitation class: 3
Flush mounting: yes
Switching neutral conductor: no
Overvoltage category: 3
Degree of pollution: 2
Additional devices possible: yes
Width in module units: 3
Protection class (IP): IP20
Ambient temperature during operation: -25 to 70 °C
Connectable conductor cross-section multi-stranded: 1-25 mm²
Connectable conductor cross-section single-stranded: 1-35 mm²
Explosion-proof: no

Hager Circuit Breaker MCS310: further details
3-pole circuit breaker, 6kA, C characteristic, 10A, Quick Connect, 3 modules. Circuit breaker with QuickConnect terminal according to DIN EN 60898-1 (VDE 0641 Part 11), outgoing up to 16A and incoming for the distribution up to 63A, with delayed thermal tripping for overload protection and electromagnetic tripping for short-circuit protection. Suitable for retrofitting of additional devices. Labeling option directly on the device and individual removal from the phase rail connection by unlocking the DIN rail quick fastening.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
70 mm
Width
52.50 mm
mounting style
Flush-mounted
number of poles
3
Item number
30441248

General information

Manufacturer
Hager
Category
Residual-current device
Manufacturer no.
MCS310
Release date
19.4.2021

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Flush-mounted
number of poles
3
Tripping characteristic
C/10 ka
Rated current
10 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
500 V
Protection type (IP code)
IP20

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
52.50 mm
Height
83.40 mm

Package dimensions

Length
9.20 cm
Width
7.20 cm
Height
5.60 cm
Weight
256 g
