Hager HAG MCS313 C13 built-in automatic 3p Quick Connect

Ratings
Delivered between Sat, 21.6. and Thu, 3.7.
More than 10 items in stock at supplier

Product details

Hager Circuit Breaker MCS313

Manufacturer: Hager
Description: Circuit breaker 3p, C-13A 6kA 3M QC
Type: MCS313
Installation depth: 70 mm
Tripping characteristic: C
Number of poles (total): 3
Number of protected poles: 3
Rated current: 13 A
Rated voltage: 400 V
Rated insulation voltage Ui: 500 V
Rated impulse voltage withstand Uimp: 4 kV
Voltage type: AC
Rated breaking capacity Icn according to EN 60898 at 400 V: 6 kA
Rated breaking capacity Icu according to IEC 60947-2 at 400 V: 10 kA
Frequency: 50..60 Hz
Energy limitation class: 3
Flush-mounted: yes
Switchable neutral conductor: no
Overvoltage category: 3
Degree of pollution: 2
Additional devices possible: yes
Width in division units: 3
Protection class (IP): IP20
Ambient temperature during operation: -25..70 °C
Connectable conductor cross-section multi-stranded: 1..25 mm²
Connectable conductor cross-section single-stranded: 1..35 mm²
Explosion-proof: no

Hager Circuit Breaker MCS313: additional details
3-pole circuit breaker 6kA C-characteristic 13A QuickConnect 3 modules. Circuit breaker with QuickConnect terminal according to DIN EN 60898-1, outgoing up to 16A and incoming for distribution up to 63A, with time-delayed thermal tripping device for overload protection and electromagnetic tripping device for short-circuit protection. Suitable for retrofitting additional devices. Labeling option directly on the device and individual removal from the phase rail connection by unlocking the DIN rail quick fastening.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
70 mm
mounting style
Top-hat rail
number of poles
3
Item number
32149731

General information

Manufacturer
Hager
Category
Residual-current device
Manufacturer no.
MCS313
Release date
28.6.2023

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Top-hat rail
number of poles
3
Tripping characteristic
C
Rated current
13 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
500 V
Protection type (IP code)
IP20

Origin

Country of origin
France

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm

30-day right of return if unopened
24 Months Warranty (Bring-in)
