Gewiss GEWI GW92566 Miniature circuit breaker (MCB) B-10A 10 kA 3-pole 3HP

Gewiss Circuit Breaker GW92566

Manufacturer: Gewiss
Designation: Circuit Breaker B10A 10 KA 3P
Type: GW92566
Installation Depth: 72 mm
Tripping Characteristic: B
Number of Poles (total): 3
Number of Protected Poles: 3
Rated Current: 10 A
Rated Voltage: 400 V
Rated Insulation Voltage Ui: 500 V
Rated Impulse Voltage Uimp: 4 kV
Rated Breaking Capacity Icn according to EN 60898 at 230 V: 10 kA
Type of Voltage: AC
Rated Breaking Capacity Icn according to EN 60898 at 400 V: 10 kA
Rated Breaking Capacity Icu according to IEC 60947-2 at 230 V: 25 kA
Rated Breaking Capacity Icu according to IEC 60947-2 at 400 V: 15 kA
Frequency: 50..60 Hz
Power Loss: 5.94 W
Energy Limitation Class: 3
Flush Mounting: No
Switching Neutral Conductor: No
Overvoltage Category: 3
Degree of Pollution: 3
Additional Devices Possible: Yes
Width in Division Units: 3
Protection Class (IP): IP20
Ambient Temperature During Operation: -25..60 °C
Connectable Conductor Cross-Section Multi-Wire: 35 mm²
Connectable Conductor Cross-Section Single-Wire: 35 mm²
Explosion Protected: No

Gewiss Circuit Breaker GW92566: Additional Details
Miniature Circuit Breaker (MCB) according to EN60898-1, with time-delayed thermal overload release and electromagnetic short-circuit release. On the left side, a RESTART reactivation device RM TOP, a RESTART remote drive CM, or two auxiliary devices can be alternatively mounted. With labeling window on the device. Connection (max): 35 mm² with insulated plug-in protection. The connection screws can be equipped with a sealable cover. The switch lever can be sealed in both the ON and OFF positions or locked with a padlock using a lever lock.
