Esylux Esyluxpresence detectorPDCE360i/24opalmatt24m
12 mMore than 10 pieces in stock at third-party supplier
Product details
Presence detector with 360° detection range for recessed ceiling mounting. Range of up to 24 m in diameter for use in offices, classrooms, conference rooms, and passage areas with daylight. Ideally suited for installation at great heights up to 10 m, such as sports halls and warehouses. 16 A high-power relay, especially suitable for switching capacitive loads such as electronic ballasts, parallel-compensated fluorescent lamps, compact fluorescent lamps, and energy-saving lamps. Automatic light control depending on presence and daylight. Programmable by remote control, including continuous light ON/OFF and automatic read-in function of the current light value. Permanently stored factory program ensures immediate operational readiness. Additional pushbutton input for individual manual switching of the lighting. Detector can be used as fully or semi-automatic. Extension of the detection range by connecting additional units.
Motion sensor type | Presence sensor |
type of sensor | PIR |
coverage angles | 360° |
Range | 12 m |
mounting style | Flush-mounted |
Item number | 13048471 |
Manufacturer | Esylux |
Category | Motion sensors |
Manufacturer no. | EP10510724 |
Release date | 7.4.2020 |
External links |
Colour | White |
Material group | Plastic |
Material | Polycarbonate (PC) |
Motion sensor type | Presence sensor |
Application range | Indoor |
type of sensor | PIR |
coverage angles | 360° |
Range | 12 m |
Protection type (IP code) | IP40 |
mounting style | Flush-mounted |
Power supply | Electrical connection |
Power consumption | 0.30 W |
Smart home | Not compatible |
Requires Smart Home Hub | No |
Transmission type | Funk, Wi-Fi |
Control type | Remote control |
Country of origin | Germany |
CO₂ emissions | 43.57 kg |
Climate contribution | CHF 1.04 |
Items per sales unit | 1x |
Width | 8.20 cm |
Height | 3.20 cm |
Weight | 236 g |
