Eaton RCD switch, 25A, 2p, 30mA, type G 235449

Residual current circuit breaker PFIM-25/2/003-G 2P 25A 0.03A Type AC/G - 235449. Lift and drive terminals from the top and bottom. Free access to the terminals with integrated busbar. Auxiliary contacts Z-HK and Z-NHK mounted, one half blinking contact position red/green. Usable with conventional lamps with and without electronic ignition. Maximum 20 units in 1 phase. Switching position arbitrary, power supply direction arbitrary. Tripping independent of mains voltage. The 4-pole circuit breaker can be used as a 3-pole circuit breaker by using terminals 1-2, 3-4, and 5-6 (+ busbar). The 4-pole circuit breaker can be used as a 2-pole circuit breaker by using terminals 5-6. The circuit breaker should be tested monthly by pressing the "Test" button, which should cause the circuit breaker to trip. The test function checks the operation of the residual current circuit breaker; it does not alter the earth resistance RE measurement value or the insulation resistance of the cables. Type G: Circuit breaker with increased resistance to surges. Prevents unwanted tripping due to surges. Such cases occur, for example, with devices that have a large group of fluorescent lamps, in long cables, in X-ray machines, in heating devices with large surfaces, when starting large electric motors, and with reduced atmospheric overvoltage. Technical data: Number of poles: 2. Rated voltage: 230/400 V, 50 Hz. Rated current: 25 A. Rated short-circuit current: 10 kA. Sensitivity: AC. Mounting: TS35 rail. Protection class: IP20.
