Eaton Electronic FI/LS combination, 16 A, 168270

The electronic RCD/MCB combination from Eaton offers a reliable solution for the protection of electrical systems. With a rated current of 16 A and a rated residual current of 30 mA, this device ensures high safety against fault currents. The combination of residual current circuit breaker and miniature circuit breaker is independent of mains voltage and features a red-green contact position indicator that clearly signals the operating status. The type C tripping characteristic provides a time-delayed tripping, which is particularly advantageous for high inrush currents. Additionally, the device is suitable for ambient temperatures ranging from -25 to 40 °C and offers protection class IP20. It is designed for flush mounting, and the connection cross-section is suitable for solid and flexible conductors from 1 to 25 mm². This combination is ideal for use in residential and commercial buildings to ensure a high safety standard.

• High-quality combination of residual current and miniature circuit breaker
• Mains voltage independent with contact position indicator
• Type C tripping characteristic for time-delayed tripping
• Suitable for ambient temperatures from -25 to 40 °C
• Protection class IP20 for safe operation indoors.
