D-Link DAP-2680

1300 Mbit/s
Delivered between Tue, 1.7. and Mon, 7.7.
More than 10 items in stock at third-party supplier
Supplied by
free shipping

Product details

The DAP-2680 utilizes the 802.11ac Wave 2 standard and reliably delivers the highest transmission speeds with maximum data rates of up to 450 Mbps over the 2.4 GHz band and 1300 Mbps over the 5 GHz band. The DAP-2680 supports MU-MIMO technology, allowing multiple devices to receive a high-bandwidth Wi-Fi signal simultaneously, distributing data more efficiently and enabling you to benefit from the fastest possible Wi-Fi in your office. Coupled with the supported Wi-Fi Multimedia (WMM) Quality of Service (QoS) feature, this makes it an ideal access point for audio, video, and voice applications. When QoS is enabled, the DAP-2680 can automatically prioritize traffic based on the type of interactive streaming, such as HD movies or VoIP. The QoS feature can be adjusted via the DAP-2680's web interface, where individual priority rules can be selected from a dropdown menu. Additionally, the DAP-2680 supports load balancing and ensures optimal performance by limiting the maximum number of users per access point.

With the DAP-2680, network administrators can provide an excellently controllable and highly robust wireless network with simultaneous dual-band connections. The DAP-2680 delivers optimal network coverage in the 2.4 GHz band (802.11b, 802.11g, and 802.11n) as well as in the 5 GHz band (802.11a, 802.11n, and 802.11ac). The DAP-2680 can be mounted on the ceiling or wall or placed on a desk, meeting any Wi-Fi requirements. For more complex installations, the DAP-2680 features integrated 802.3at Power over Ethernet (PoE), allowing the device to be installed in areas where no power outlets are available.

Key specifications

Wi-Fi standard
Wi-Fi 1 / 802.11bWi-Fi 2 / 802.11aWi-Fi 3 / 802.11gWi-Fi 4 / 802.11nWi-Fi 5 / 802.11ac
Wi-Fi frequency band
Single band
PoE Standard
802.3af (PoE)
Operating modes
Access point
Area of application
Business
Number of RJ45/LAN ports
1
Max. port speed
1000 Mbit/s
Item number
10152812

General information

Manufacturer
D-Link
Category
Access points
Manufacturer no.
DAP-2680
Release date
27.11.2018
External links

Access point properties

Operating modes
Access point
Number of antennas
3 x
Antenna gain
4.20 dB
Number of RJ45/LAN ports
1
Max. port speed
1000 Mbit/s
Protection type (IP code)
IP20
Access Point Functions
PoE capableWireless uplink

Wi-Fi standard

Wi-Fi standard
Wi-Fi 1 / 802.11bWi-Fi 2 / 802.11aWi-Fi 3 / 802.11gWi-Fi 4 / 802.11nWi-Fi 5 / 802.11ac
5 GHz transfer rate
1300 Mbit/s
2.4 GHz transfer rate
450 Mbit/s
Wi-Fi frequency band
Single band
Wi-Fi encryption
WPAWPA2

Application range

Area of application
Business
Installation place
TableWall

Power supply

Power supply
Electrical connection
PoE Standard
802.3af (PoE)
Power consumption
17.53 W

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Power adapter

Product dimensions

Length
19 cm
Width
19 cm
Height
4.48 cm
Weight
580 g

Package dimensions

Length
27.50 cm
Width
20.20 cm
Height
11.50 cm
Weight
1.09 kg

30-day right of return
24 Months Warranty (Bring-in)
