Cambium Networks XV2-2T1XA00-EU - XV2-2T1 Wi-Fi 6 Outdoor AP (EU)

Dual radio with 120° sector antenna for 2.4 GHz and 5 GHz bands. It supports the Wi-Fi 6 802.11ax standard, 2x2 MU-MIMO with a maximum capacity of 1,774 Mbps. The access point is equipped with a 2.5G multigigabit port and PoE 802.3at power supply, as well as one 1G port with PoE-out function. To reduce interference in the 2.3-2.5 GHz band, the device is equipped with an LTE filter.

Key features:

• Outdoor dual AP 2.4 GHz + 5 GHz
• 2.4 GHz: 802.11n 2x2 MIMO, max. 574 Mbit/s
• 5 GHz: 802.11ac, 2x2 MU-MIMO, max. 1,200 Mbit/s
• 1x 2.5G Multigig LAN RJ-45 port with PoE 802.3at support
• 1x 1G LAN port RJ-45 with PoE-out support
• PoE power supply
• LTE filter 2.4 GHz
• HE 120° sector antenna
• Free online tool for designing your Cambium WLAN network

Wireless functions:

• Radio frequency: 2.4 + 5 GHz (dual band)
• WLAN standards: 802.11ac, 802.11ac - wave 2, 802.11ax, 802.11n, 802.11a, 802.11b/g
• MU-MIMO: Yes
• Transmission speed - 5 GHz [Mbit/s]: 1201
• Transmission speed - 2.4 GHz [Mbit/s]: 574
• Transmission power 2.4 GHz [dBm]: 35
• Transmission power 5 GHz [dBm]: 36
• Security: WPA, WPA2, WPA3
• 2.4 GHz MIMO: 2 x 2
• 5 GHz MIMO: 2 x 2
• Antenna type: Built-in
• Internal antennas: 2
• Roaming: Yes
• Antenna gain [dBi]: 11, 13

Connectors and interfaces:

• LAN speed: (1) 100/1000/2500 Mbit/s + (1) 10/100/1000 Mbit/s
• Gigabit LAN: Yes
• Other functions: Bluetooth

Performance:

• Power over Ethernet: 802.3at, 802.3bt
• PoE type: PoE-Out + PoE-In
• PoE budget [W]: 30
• Max. power consumption [W]: 20

Physical characteristics:

• Protection class: IP67
• Purpose: Outdoor
• Operating temperature [°C]: -40 to 65
• Weight [g]: 1200
• Width [mm]: 200
• Height [mm]: 582
• Depth [mm]: 80

Software:

• Operating mode: Access point
• Management: Web management, Cambium cnMaestro Cloud.
