Allnet PoE injector MultiGigabit &bull PoE bt 90W &bull 1G/2.5G/5G/10G PoE & PoE bt (15.4W/30W/60W/9

The ALLNET PoE Injector ALL-PI103MG-BT90-10G is a highly advanced PoE injector that offers a maximum output power of 90 W per PoE port. It supports multigigabit speeds ranging from 1 G to 10 G, making it ideal for modern network environments. The injector is housed in a robust metal casing and features an IP20 protection rating, safeguarding it against dust and mechanical impacts. With a wide input voltage range of 100 to 240 VAC and an operating temperature range of -20 °C to +50 °C, it is suitable for various operating conditions. Additionally, the PoE injector is equipped with effective ESD surge protection, which protects connected devices from damage. It meets all relevant safety standards, including FCC, CE, and RoHS, ensuring high reliability and safety during operation. The flexible mounting options allow for easy installation on walls or tables, making it a practical solution for various applications such as PTZ cameras and digital signage.

• Supports 1 Multigigabit 10G PoE Port (1G/2.5G/5G/10G) + 1 10G (1G/2.5G/5G/10G LAN) RJ45 Port
• Supports IEEE802.3af (15.4 W), IEEE802.3at (30 W), and IEEE802.3bt (90 W)
• Input power supply support 100-240 VAC
• Metal casing, IP20 protection rating, operating temperature -20 to 50 °C
• Supports port surge protection: Differential mode 2 kV, Common Mode 6 kV ESD: Contact 6 kV, Air 8 kV.
