ABB Contactor 100-250VAC/DC AF09-30-10-13

ABB Stotz S&J Contactor AF09-30-10-13

Manufacturer: ABB Stotz S&J
Designation: Contactor
Voltage Type: 100-250 VAC/DC
Rated Control Supply Voltage Us at AC 50 Hz: 100-250 V
Rated Control Supply Voltage Us at AC 60 Hz: 100-250 V
Rated Control Supply Voltage Us at DC: 100-250 V
Voltage Type for Actuation: AC/DC
Rated Operational Current Ie at AC-1, 400 V: 25 A
Rated Operational Current Ie at AC-3, 400 V: 9 A
Rated Operational Power at AC-3, 400 V: 4 kW
Rated Operational Power NEMA: 1.4914 kW
Suitable for Series Installation: No
Number of Auxiliary Contacts as NO Contacts: 1
Connection Type Main Circuit: Screw Connection
Number of NO Contacts as Main Contacts: 3

The 3-pole AF09 contactors represent the compact series with AC/DC control and very wide coil voltage ranges. They switch power circuits with motors, light inductive, or non-inductive loads. Only 4 coils cover control voltages from 20-500 VDC to 24-500 VAC. They have integrated overvoltage protection and do not require additional suppressors. All integrated or retrofittable NC auxiliary contacts are designed as mirror contacts according to IEC 60947-5-1 appendix L. Further accessories such as timing elements, wiring aids, and interlocking elements complete the range.
EAN: 3471523110038.
