ABB Circuit breaker 32A pro S203P-C32 M compact 3-pole

ABB Stotz S&J Circuit Breaker S203P-C32

Manufacturer: ABB Stotz S&J
Designation: Circuit Breaker C, 15/25 kA, 32 A, 3P
Type: S203P-C32
Installation Depth: 69 mm
Tripping Characteristic: C
Number of Poles (total): 3
Number of Protected Poles: 3
Rated Current: 32 A
Rated Voltage: 400 V
Rated Insulation Voltage Ui: 440 V
Rated Impulse Voltage Uimp: 4 kV
Rated Switching Capacity Icn according to EN 60898 at 230 V: 12.5 kA
Voltage Type: AC
Rated Switching Capacity Icn according to EN 60898 at 400 V: 15 kA
Rated Switching Capacity Icu according to IEC 60947-2 at 230 V: 25 kA
Rated Switching Capacity Icu according to IEC 60947-2 at 400 V: 15 kA
Frequency: 50..60 Hz
Energy Limitation Class: 3
Flush Mounting: No
Switching Neutral Conductor: No
Overvoltage Category: 3
Degree of Pollution: 3
Additional Devices Possible: Yes
Width in Division Units: 3
Protection Class (IP): IP20
Ambient Temperature during Operation: -25..55 °C
Connectable Conductor Cross-Section Multi-stranded: 0.75..16 mm²
Connectable Conductor Cross-Section Solid: 0.75..25 mm²
Explosion-Proof: No

The S 200 P series circuit breakers protect cables and conductors against overload and short circuits according to DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN 60947-2, and UL 1077. For better visibility during wiring, the connection opening for conductors is located above the connection opening for the phase bus. Conductor cross-sections up to 25 mm² can be directly connected to the device via the terminal with insulation in protection class IP20. The extensive range of accessories provides everything you need for your installation tasks. Numerous approvals make the S 200 P suitable for worldwide use. Each device undergoes three intensive tests for quality and performance before delivery. EAN: 4016779590648.
